CyberPower

CyberPower Smart App Sinewave uninterruptible power supply (UPS) Line-Interactive 3 kVA 3000 W 9 AC outlet(s)

Part number PR3000RTXL2UCN

CYBERPOWER PR3000RTXL2UCN UPS 3000VA/3000W 120 VAC NEMA L5-30P

Battery Backup
Line-Interactive Topology
Automatic Voltage Regulation (AVR)
Sine Wave Output
Battery Equalization Technology

Manufacturer: CyberPower
Part number: PR3000RTXL2UCN
Condition: New
Category: Power & Rack Equipment › Power Equipment
1GPA category: Hardware

Overview

The PR3000RTXL2UCN is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower’s Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment.

The Smart App Sinewave PR3000RTXL2UCN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR3000RTXL2UCN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options.

This model accepts the BP48VP2U02 Extended Battery Module (EBM) for expanded runtime during power outages and includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system. Includes built-in cloud monitoring.

With a $400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower’s commitment to the quality of the PR3000RTXL2UCN.

Specifications

Features
UPS topology	Line-Interactive
Output power capacity	3 kVA
Output power	3000 W
Waveform	Sine
Input operation voltage (min)	75 V
Input operation voltage (max)	149 V
Input frequency	47/63 Hz
Output operation voltage (max)	120 V
Output frequency	50/60 Hz
Maximum current	30 A
Surge energy rating	2430 J
Response time	13 ms
Heat dissipation	192.5 BTU/h
Power factor	1
EMI/RFI noise filtering	Yes
Noise level	57.5 dB
Surge protection	Yes
Audible alarm(s)	Yes
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm

Ports & interfaces
AC outlet types	NEMA L5-30R, NEMA 5–20R
Power plug	NEMA 5-20R
AC outlets quantity	9 AC outlet(s)
Serial interface	Yes
Serial interface type	RJ-45
Serial ports quantity	1

Battery
Battery replacement accessibility	End-user
Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	9 Ah
Battery voltage	12 V
Number of batteries supported	4
Typical backup time at full load	1.7 min
Typical backup time at half load	7 min
Battery recharge time	3 h
Hot-swap battery	Yes
Replacement battery cartridge	RB1290X4J

Design
Form factor	Rackmount/Tower
Housing material	Metal
Rack capacity	2U
Cable length	3 m
Product colour	Black
Control type	Buttons
Display type	LCD
LED indicators	Power, Fault, Battery level

Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 14999 m

Packaging content
Cables included	USB cable, Serial

Weight & dimensions
Width	434 mm
Depth	500 mm
Height	86 mm
Weight	34.2 kg

Packaging data
Package width	5524 mm
Package depth	6159 mm
Package height	2667 mm
Package weight	40.5 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
