CyberPower CP1500AVRLCDTAA uninterruptible power supply (UPS) Line-Interactive 1.5 kVA 900 W 12 AC outlet(s)
Part number CP1500AVRLCDTAA
1500VA/900W MINI-TOWER AVR UPS 12 OUTLET LCD SERIAL/USB 3YR WTY
- Capacity: 1500 VA / 900 W
- Topology: Line Interactive
- Waveform: Simulated Sine Wave
- Output: 120 VAC ± 5%
- Runtime (half/full): 12 minutes / 3 minutes
- Outlets: 12 (6 surge, 6 surge + battery backup)
- Communication: USB, Serial
- Data line protection: Ethernet, Coaxial
- Manufacturer
- CyberPower
- Part number
- CP1500AVRLCDTAA
- Term
- Term: 36 months
- Condition
- New
- Category
- Power & Rack Equipment › Rack Equipment
- 1GPA category
- Hardware
Overview
A mini-tower UPS with line interactive topology, the CyberPower Intelligent LCD CP1500AVRLCDTAA provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and VoIP phone systems. The CP1500AVRLCDTAA uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP1500AVRLCDTAA comes with a three-year warranty (including coverage of batteries), a $500,000 Connected Equipment Guarantee, and complies with the U.S. Trade Agreement Act (TAA).
Battery Backup
Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
Automatic Voltage Regulation (AVR)
AVR increases the AC power and maintains a safe voltage level without switching to battery mode and conserving battery life.
Multifunction LCD
Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
Data Line Protection
Prevents power surges that travel through coaxial and Ethernet lines from causing damage to electronics.
Line Interactive Topology
Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
Simulated Sine Wave Output
Provides a manufactured waveform output to supply cost-effective battery backup power for equipment that does not require sine wave output.
ENERGY STAR
This model is an ENERGY STAR® certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.
GreenPower UPS™ Bypass Design
A patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
Ultra Quiet Design
Minimizes noise during operation for a quieter work environment.
PowerPanel® Personal Software
Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available.
Specifications
| UPS topology | Line-Interactive |
|---|---|
| Output power capacity | 1.5 kVA |
| Output power | 900 W |
| Waveform | Sine |
| Input operation voltage (min) | 90 V |
| Input operation voltage (max) | 142 V |
| Input frequency | 57/63 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 120 V |
| Output frequency | 60 Hz |
| Surge energy rating | 1500 J |
| Response time | 4 ms |
| EMI/RFI noise filtering | Yes |
| Surge protection features | Coax |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
| AC outlet types | NEMA 5-15R |
|---|---|
| Power plug | NEMA 5-15P |
| AC outlets quantity | 12 AC outlet(s) |
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
| Number of batteries supported | 2 |
|---|---|
| Typical backup time at full load | 3 min |
| Typical backup time at half load | 12 min |
| Battery recharge time | 8 h |
| Hot-swap battery | Yes |
| Form factor | Mini Tower |
|---|---|
| Cable length | 2 m |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Fault, Power |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15239 m |
| Cables included | USB cable |
|---|
| Width | 99 mm |
|---|---|
| Depth | 356 mm |
| Height | 279 mm |
| Weight | 11.3 kg |
| Package width | 200.7 mm |
|---|---|
| Package depth | 444.5 mm |
| Package height | 374.6 mm |
| Package weight | 11.3 kg |
