Overview
The Club 3D DisplayPort™ 1.4 HBR3 cable enables the connection of your DisplayPort™ supported (Gaming) PC or Laptop to an (Ultra) High Resolution Monitor or other DisplayPort™ supported device. DisplayPort™ 1.4 adds support for Display Stream Compression 1.2 (DSC), Forward Error Correction, and extends the maximum number of inline audio channels to 32.
It features locking DisplayPort™ connectors providing a secure, dependable connection. Simply press the built-in one- touch latch button to unlock the connector. The soft UltraFlex jacket protects the cable from bends and deformation damage. Certified by Vesa.
Specifications
Features
| Connector contacts plating | Copper |
|---|
| Maximum resolution | 7680 x 4320 pixels |
|---|
| Maximum refresh rate | 144 Hz |
|---|
| HDCP | Yes |
|---|
| DisplayPort Content Protection (DPCP) | Yes |
|---|
| 3D | Yes |
|---|
| Cable length | 2 m |
|---|
| Connector 1 | DisplayPort |
|---|
| Connector 2 | DisplayPort |
|---|
| Connector 1 gender | Male |
|---|
| Connector 2 gender | Male |
|---|
| Latching connectors | Yes |
|---|
| Product colour | Black |
|---|
| Number of shielding layers | 4 |
|---|
| AWG wire size | 28 |
|---|
| Data transfer rate | 32.4 Gbit/s |
|---|
| Plug and Play | Yes |
|---|
| HBR3 support | Yes |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
| Certification | RoHS, CE, WEEE, REACH, Vesa |
|---|
Weight & dimensions
| Weight | 141 g |
|---|
Packaging data
| Package width | 150 mm |
|---|
| Package depth | 100 mm |
|---|
| Package height | 215 mm |
|---|
| Package weight | 6 g |
|---|
| Package type | Polybag |
|---|
| Paper/cardboard packaging weight | 0 g |
|---|
| Plastic packaging weight | 10 g |
|---|
| Total plastic packaging weight | 250 g |
|---|
| Total paper/cardboard packaging weight | 0 g |
|---|
Packaging content
| Quantity per pack | 1 pc(s) |
|---|
Logistics data
| Harmonized System (HS) code | 8544 4290 |
|---|
| Products per master (outer) case | 10 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
