CHIEF MANUFACTURING
Chief Large Outdoor Flat Panel Single Ceiling and Pedestal Mount System - OD34
Part number OD34
3-4FT PROJ1 DISCOUNT BUNDLE
- •Weatherproof design meets UL 2442 Part 2 – Suitable for Outdoor Use with corrosion resistant paint, UV-rated plastics and stainless-steel hardware.
- •The system comes in three pieces, the mount, column and plate for better customization to fit the particular installation requirements.
- •The four-step installation process keeps each piece separate for a safer, more manageable lifting load
- •Tilt range of +7.6 to -20 degrees has set locking points to eliminate guesswork when adjusting multiple displays
- •Universal interface fits most indoor and outdoor displays with up to 800 x 400 mm max VESA® pattern
- Manufacturer
- CHIEF MANUFACTURING
- Part number
- OD34
- Condition
- New
- Category
- Accessories › Monitor Accessories
- 1GPA category
- Hardware
Overview
All the pieces needed for a single ceiling or floor mounted install
The OLCM1U Outdoor ceiling and pedestal mount is built to withstand rain, humidity and ocean air, sun exposure and high winds. Wind-compatible to 2000 ft-lbs maximum moment force – used in engineering calculations to ensure a wide range of install configurations meet local safety requirements.
Specifications
| Maximum weight capacity | 113.4 kg |
|---|---|
| Minimum screen size | 106.7 cm (42") |
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 113.4 kg |
| Maximum screen size | 165.1 cm (65") |
| Mounting type | Ceiling |
| Minimum VESA mount | 200 x 100 mm |
| Maximum VESA mount | 800 x 400 mm |
| Panel mounting interface | 800 x 400,200 x 100 mm |
| Tilt adjustment | Yes |
|---|
| Product colour | Black |
|---|---|
| Certification | TAA |
| Package width | 121.9 mm |
|---|---|
| Package depth | 101.6 mm |
| Package height | 106.7 mm |
| Package weight | 79.8 kg |
| Orientation | Landscape |
|---|---|
| Compliance certificates | TAA |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
