Overview
Chief's ConnexSys™ Video Wall Mounting System solves common video wall challenges of speed, alignment, serviceability and rigidity. The ConnexSys™ Video Wall Mounting System provides the ability to level each row once by using strut channel to connect multiple mounts together with a simple-to-install system that can handle the largest requirements.
Read the complete story of ConnexSys™ here.
Specifications
Mounting
| Maximum weight capacity | 68.04 kg |
|---|
| Minimum screen size | 106.7 cm (42") |
|---|
| Number of displays supported | 1 |
|---|
| Maximum screen size | 2.03 m (80") |
|---|
| Minimum VESA mount | 200 x 100 mm |
|---|
| Maximum VESA mount | 700 x 400 mm |
|---|
| Panel mounting interface | 200 x 200,300 x 300,400 x 200,400 x 400,600 x 400 |
|---|
| Mounting type | Wall |
|---|
Ergonomics
| Height adjustment | Yes |
|---|
| Tilt angle range | -2.5 - 4° |
|---|
Design
| Product colour | Black |
|---|
| Housing material | Steel |
|---|
| Compatibility | MIS-F (200x200mm)
MIS-F (300x300mm)
MIS-F (400x200mm)
MIS-F (400x400mm)
MIS-F (600x400mm) |
|---|
| Certification | ULCERT |
|---|
Packaging content
| Mounting kit | Yes |
|---|
Weight & dimensions
| Width | 901.7 mm |
|---|
| Depth | 102 mm |
|---|
| Height | 530.9 mm |
|---|
Packaging data
| Package weight | 20 kg |
|---|
Logistics data
| Harmonized System (HS) code | 85299097 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
