Canon EF-S 10-18mm f/4.5-5.6 IS STM Lens
Part number 9519B002
EF-S ULTRA-WIDE ZOOM LENS EF-S10-18MM F4.5-5.6 IS STM CONST
- Component for: SLR Ultra-wide lens Black
- Lens structure (elements/groups): 14/11
- Maximum aperture number: 29
- Closest focusing distance: 0.22 m
- Manufacturer
- Canon
- Part number
- 9519B002
- Condition
- New
- Category
- Accessories › Camera Accessories
- 1GPA category
- Hardware
Overview
The EF-S 10-18mm f/4.5-5.6 IS STM lens combines optical excellence with cutting-edge performance, providing an ultra-wide angle of view in a compact, portable package, perfect for EOS cameras with an APS-C sensor. It has a 4 group optical zoom system and includes a large-diameter element, an aspherical lens element, a UD lens element and enhanced lens coatings for high-contrast, high-resolution images with minimal glare and aberration. A circular, 7-blade aperture helps ensure fine background blur and the Canon Optical Image Stabilizer system provides up to four equivalent stops of shake correction. The lens has a stepping motor (STM) and a refined focus mechanism for smooth and continuous AF during video recording. It also has a rear focusing system, plus a high speed CPU and improved AF algorithm for high-speed AF; and offers full-time manual focus for quick adjustments. The EF-S 10-18mm f/4.5-5.6 IS STM delivers reliable, speedy and quiet wide-angle performance, making it an ideal lens for everyday photography, travel, stills and video recording.
Specifications
| Component for | SLR |
|---|---|
| Lens type | Ultra-wide lens |
| Lens structure (elements/groups) | 14/11 |
| Focus adjustment | Auto/Manual |
| Lens viewing angle, diagonal | 107°30' - 74°20' |
| Focal length range | 10 - 18 mm |
| Minimum aperture number | 22 |
| Number of diaphragm blades | 7 |
| Closest focusing distance | 0.22 m |
| Maximum aperture number | 29 |
| Macro ratio | 1:4.5 |
| Zoom capability | Yes |
| Lens mount interface | Canon EF-S |
| Image stabilizer | Yes |
| Camera brands compatibility | Canon |
|---|---|
| Maximum magnification | 0.15x |
| Product colour | Black |
|---|
| Length | 72 mm |
|---|---|
| Weight | 240 g |
| Diameter | 7.46 cm |
| Filter size | 67 mm |
