Canon imageFORMULA DR-G2140 Sheet-fed scanner 600 x 600 DPI A3 Black, White
Part number 3149C002
CANON IMAGEFORMULA DR-G2140 - 12 IN X 17 IN - DOCUMENT SCANNER - COLOR, GRAYSCAL
- Scanner type: Sheet-fed scanner 600 x 600 DPI
- Colour scanning Duplex scanning
- Built-in display
- A3
- Maximum scan size: 305 x 432 mm Sensor type: CIS
- USB port Ethernet LAN
- Power supply type: AC 66.5 W
- Scanning noise level: 54 dB
- Manufacturer
- Canon
- Part number
- 3149C002
- Condition
- New
- Category
- Imaging Devices › Scanners
- 1GPA category
- Hardware
Overview
Ultra-fast model takes production scanning to the next level
Optimised for customers who require exceptional high-speed productivity, superior image quality and dependable feeding performance, this A3 scanner has been created to excel in demanding environments
Productivity
Ultra-efficient scanner outputs up to 280 images per minute
Reliability
Robust, durable paper feed and transport rollers can deliver up to 70,000 scans per day
Image quality
Advanced image-processing tools deliver consistently crisp, clear, high-quality images
Specifications
| Maximum scan size | 305 x 432 mm |
|---|---|
| Optical scanning resolution | 600 x 600 DPI |
| Colour scanning | Yes |
| Duplex scanning | Yes |
| Output colour depth | 24 bit |
| Output greyscale depth | 8 bit |
| ADF scan speed (b/w, A3) | 145 ppm |
| ADF scan speed (colour, A3) | 145 ppm |
| Duplex ADF scan speed (b/w, A4) | 290 ipm |
| Duplex ADF scan speed (colour, A4) | 290 ipm |
| Scanner type | Sheet-fed scanner |
|---|---|
| Product colour | Black, White |
| Built-in display | Yes |
| Sensor type | CIS |
|---|---|
| Light source | RGB LED |
| Daily duty cycle (max) | 70000 pages |
| Scan drivers | ISIS, TWAIN, WIA |
| Scanning noise level | 54 dB |
| Standard input capacity | 500 sheets |
|---|
| Long-paper mode | Yes |
|---|---|
| Maximum ISO A-series paper size | A3 |
| Auto Document Feeder (ADF) media weight | 20 - 209 g/m² |
| USB port | Yes |
|---|---|
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| Standard interfaces | Ethernet, USB 3.2 Gen 1 (3.1 Gen 1) |
| Ethernet LAN | Yes |
|---|
| Power supply type | AC |
|---|---|
| Power consumption (typical) | 66.5 W |
| AC input frequency | 50 - 60 Hz |
| Sleep mode | Yes |
| Input voltage | 220 - 240 V |
| Power consumption (sleep) | 3.5 W |
| Width | 480 mm |
|---|---|
| Depth | 569 mm |
| Height | 315 mm |
| Weight | 25 kg |
| Bundled software | Canon CaptureOnTouch, Kofax VRS Professional |
|---|
| Sustainability certificates | EPEAT Gold |
|---|
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
|---|---|
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Operating temperature (T-T) | 10 - 35 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Operating temperature (T-T) | 50 - 95 °F |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
