Buffalo BSL-PS-G2108M network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Part number BSL-PS-G2108M
8PORT MANAGED RM GBE 802.3AT POE WEB SWITCH
- Managed L2 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 8
- MAC address table: 8192 entries
- Rack mounting
- Power over Ethernet (PoE)
- Manufacturer
- Buffalo Americas
- Part number
- BSL-PS-G2108M
- Condition
- New
- Category
- Network Devices › Switches & Hubs
- 1GPA category
- Hardware
Overview
Buffalo Technology’s new Smart Intelligent Power over Ethernet Switches gives small and medium businesses a quick and easy solution for otherwise complex network improvements and expansion.
And, with a Buffalo Switch in place, network administrators can rest assured with Buffalo’s Loop Guard warning system. A loop occurs if there is more than one path between two endpoints – possible causes are multiple connections between two network switches, or, two ports on the same switch connected to each other. With Buffalo’s new Switches the offending port from whichthe loop originates is immediately shut down and the switch gives both a buzzer and LED alert. In the past administrators might spend a considerable amount of time detecting and locating such a problem, but with Buffalo’s new switches detection and location are just a blinking light and buzzing buzz away.
Buffalo’s new Smart Intelligent switches allow businesses to gradually grow their networks as their needs expand with plug-and-play setup, come with advanced features such as VLAN tagging, and are available with 8 or 16 ports.
Specifications
| Switch type | Managed |
|---|---|
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Networking standards | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
|---|---|
| 10G support | No |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| MAC address table | 8192 entries |
|---|---|
| Store-and-forward | Yes |
| Latency (1 Gbps) | 4.5 µs |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.5 MB |
| DHCP features | DHCP client |
|---|---|
| Security algorithms | 802.1x RADIUS |
| MAC address filtering | Yes |
| Multicast support | Yes |
|---|
| Supported network protocols | SNTP, BN-ADT |
|---|
| Rack mounting | Yes |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
| Internal memory | 64 MB |
|---|---|
| Flash memory | 8 MB |
| Firmware upgradeable | Yes |
| Power consumption (typical) | 150 W |
|---|
| Power over Ethernet (PoE) | Yes |
|---|---|
| Total Power over Ethernet (PoE) budget | 30 W |
| Packet transfer speed | 14881 (10BASE-T), 148810 (100BASE-TX), 1488095 (1000BASE-T) |
|---|---|
| Power LED | Yes |
| Width | 270 mm |
|---|---|
| Depth | 31 mm |
| Height | 43 mm |
| Weight | 2.5 kg |
| User guide | Yes |
|---|---|
| Manual | Yes |
| Certification | VCCI A、UL60950-1 |
|---|
