BRAINBOXES LTD
Brainboxes 60W Single Output Industrial DIN Power Supply
Part number PW-245
60W SINGLE OUTPUT INDUSTRIAL DIN RAIL MOUNGTABLEPOWER SUPPLY
- Mains input Voltages: installed by qualified electricians only
- Universal 85-264VAC or 120-370VDC input Voltage
- Output: +24VDC, 2.5A, 60W
- Operating temperature range: -40ºC to +70ºC/-40ºF to 158ºF
- High I/O isolation test Voltage up to 4000VAC
- Over-voltage class III (Designed to meet EN61558-1 safety standards)
- Output short circuit, over-current, over-Voltage protection
- Manufacturer
- BRAINBOXES LTD
- Part number
- PW-245
- Term
- Per Ingram SKU 9VV825
- Condition
- New
- Category
- Network Devices › Switches & Hubs
- 1GPA category
- Hardware
Overview
Cost-effective, energy efficient solution for standard DIN-rail mounting, offering a high level of stability and immunity to noise.
Compliant with international standards for EMC and safety meeting IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368.
Specifications
| Power supply type | Indoor |
|---|---|
| Input voltage | 85-264 VAC or 120-370 VDC |
| Output voltage | 24 V |
| Product colour | Black |
|---|
| Operating temperature (T-T) | -40 - 70 °C |
|---|---|
| Storage temperature (T-T) | -40 - 85 °C |
| Width | 85 mm |
|---|---|
| Depth | 100 mm |
| Height | 65 mm |
| Weight | 230 g |
| Package width | 90 mm |
|---|---|
| Package depth | 133 mm |
| Package height | 64 mm |
| Package weight | 270 g |
| Quantity per pack | 1 pc(s) |
|---|
| Harmonized System (HS) code | 84718 |
|---|---|
| Export Control Classification Number (ECCN) | EAR99 |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
