BenQ RE8604FV2 interactive whiteboard 2.18 m (86") 3840 x 2160 pixels Touchscreen Grey, Black
Part number RE8604FV2
86IN IFP 4K 128GB OC2 UPGRADE BUILT IN CAMERA NFC SENSOR MIC
- Expansive app library
- Go-to Google services
- Google Docs editors
- Text-to-speech
- Multilingual translation
- Manufacturer
- BenQ
- Part number
- RE8604FV2
- Condition
- New
- Category
- Input & Output Devices › Pointing Devices
- 1GPA category
- Hardware
Overview
The essence of education
Have all the essential tools you need for effective interactive lessons.
Harness the power of Google
The EDLA-certified BenQ Board combines Google services with ever-reliable BenQ hardware and software.
A whiteboard like no other
Do more than just write or draw. EZWrite’s expandable canvas offers limitless possibilities with its rich collection of lesson tools and helpful AI features.
Essential tools for every teacher
The RE04FV2 uncomplicate your teaching experience by giving you everything you need on one board.
Enhance your lesson flow
Increase teaching efficiency with the multi-window mode, allowing you to whiteboard while using other apps on the side.
Everyone can share
InstaShare 2 lets everyone share ideas freely. Wirelessly cast lesson content and interact with any device from anywhere in the room.
Management made easy
BenQ takes out the complexity from device and user list management, significantly reducing IT workload so they can focus on other tasks.
Enhanced data security
Safeguard your data through the RE04FV2’s secure login options and access controls, regular system updates, and built-in Google Play Protect and Safe Browsing measures.
ClassroomCare®
ClassroomCare features are essential in helping schools create healthier learning spaces for students and teachers.
Antimicrobial screen
The RE04FV2 help reduce the transmission of germs in the classroom. Its touchscreen has a TÜV-certified antimicrobial coating that is 99.9% effective against common germs.
IP5X dust protection
The IEC 60529-compliant RE04FV2 screen prevents dust accumulation even in the most dust-prone environments.
Specifications
| Display diagonal | 2.18 m (86") |
|---|---|
| Display brightness | 450 cd/m² |
| Display resolution | 3840 x 2160 pixels |
| Anti-glare screen | Yes |
| HD type | 4K Ultra HD |
| Panel type | IPS |
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 30000:1 |
| Response time | 8 ms |
| Touchscreen | Yes |
| Touch technology | Multi-touch |
| Touchscreen type | Infrared |
| Number of simultaneous touchpoints | 40 |
| Touch system response time | 5 ms |
| Colour gamut | 68% |
| Working area | 1895 x 1096 mm |
| Surface material | Tempered glass |
| Hardness | 9H |
| Operating system installed | Android |
|---|---|
| Operating system version | 14.0 |
| Built-in processor | Yes |
| Processor architecture | ARM Cortex A73 + ARM Cortex A53 |
| Processor cores | 8 |
| User memory | 128 GB |
| RAM capacity | 8 GB |
| Graphics card family | ARM |
| Graphics card | Mali-G52 MP8 |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| Speaker power | 20 W |
| Built-in subwoofer | No |
| Built-in microphone | Yes |
| Number of microphone arrays | 8 |
| Aspect ratio | 16:9 |
|---|
| Wi-Fi | No |
|---|---|
| Wi-Fi standards | Not supported |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
|---|---|
| USB connector type | USB Type-A, USB Type-B, USB Type-C |
| USB 2.0 Type-B Touch ports quantity | 2 |
| HDMI ports quantity | 4 |
| USB Type-C ports quantity | 2 |
| HDMI version | 2.0 |
| HDMI output ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 65 W |
| DisplayPort version | 1.2a |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Line-in | Yes |
| Line-out | Yes |
| OPS slot | 1 |
| S/PDIF out port | Yes |
| Headphone connectivity | 3.5 mm |
| RS-232 ports | 1 |
| Product colour | Grey, Black |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 800 x 600 mm |
| Wall mountable | Yes |
| Certification | TÜV |
| Ambient light sensor | Yes |
|---|---|
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Operating hours (hours/days) | 18/7 |
| Power consumption (typical) | 106.8 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 80% |
| Width | 1961.8 mm |
|---|---|
| Depth | 87.7 mm |
| Height | 1183.4 mm |
| Weight | 65.8 kg |
| Package width | 2095 mm |
|---|---|
| Package depth | 185 mm |
| Package height | 1265 mm |
| Package weight | 79.6 kg |
| Cables included | HDMI, USB, USB Type-C, VGA |
|---|---|
| Remote control included | Yes |
| Mounting kit | Yes |
| Mounting brackets included | Yes |
| Stylus included | Yes |
| Number of stylus pens | 2 |
| Bundled software | EZWrite 6.0, InstaShare 2, DMS, AMS, Floating Tool, X-Sign Broadcast |
| Sustainability certificates | ENERGY STAR |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
