Barco
Barco ClickShare C-5 Gen2 wireless presentation system HDMI Dongle
Part number R9861605US
CLICKSHARE C-5 GEN2 US
- Entry-level wireless presentation model
- Content sharing with the ClickShare App and native BYOD
- 100% secure, encrypted and cloud managed
- Manufacturer
- Barco
- Part number
- R9861605US
- Condition
- New
- Category
- Communications › Video/Audio Conf.
Overview
Simple, one-click wireless presentation for huddle spaces
The ClickShare C-5 brings simple, wireless collaboration to small meeting rooms and huddle spaces. You and your guests can easily share content to the room display, with just one click in the ClickShare App, from any laptop or mobile device. It offers a full BYOD experience, including screen mirroring with Airplay, GoogleCast and Miracast.
Specifications
| Form factor | Dongle |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Maximum resolution (HDMI) | 3840 x 2160 pixels |
|---|---|
| Supported video modes | 2160p |
| AirPlay mirroring | Yes |
| Maximum frame rate | 30 fps |
| Miracast | Yes |
| Google Cast | Yes |
| Number of simultaneously connected devices (max) | 32 |
| Smartphone/tablet remote support | Yes |
| Web-based management | Yes |
|---|---|
| On/off switch | Yes |
| Wi-Fi standards | 802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
|---|---|
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Frequency band | 2.4, 5 GHz |
| Dual-band | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.15.1 |
| Security algorithms | 802.1x RADIUS, WPA2-PSK |
| Maximum operating distance | 30 m |
| Interface | HDMI |
|---|---|
| Number of HDMI outputs | 1 |
| HDMI version | 1.4b |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DC-in jack | Yes |
| Power source type | AC, USB |
|---|---|
| Input voltage | 110 - 220 V |
| Power consumption (max) | 24 W |
| Power consumption (typical) | 10 W |
| Suitable for use in country/location | United States |
| Windows operating systems supported | Windows 11 Enterprise x64, Windows 10, Windows 11 Home, Windows 10 Education, Windows 11 Pro, Windows 10 Education x64, Windows 11 x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise |
|---|---|
| Mac compatibility | Yes |
| Mac operating systems supported | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Mobile operating systems supported | Android 10.0, Android 11.0, Android 12.0, Android 13.0, Android 14.0, Android 9.0, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16 |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 0 - 85% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Width | 135 mm |
|---|---|
| Depth | 135 mm |
| Height | 34 mm |
| Weight | 900 g |
| Quick start guide | Yes |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
