ATEN VS482B video switch HDMI
Part number VS482B
4-PORT TRUE 4K HDMI SWITCH WITH DUAL OUTPUT
- Allows up to 4 HDMI A/V sources to be connected to 2 HDMI displays
- Superior video quality – up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4); HDR supported
- HDMI 2.0 (3D, Audio Return Channel, Deep Color); HDCP 2.2 compliant
- Supports Auto Switch – the VS482B automatically switches to a newly plugged-in source
- Audio Return Channel (ARC) function – connects an HDMI cable to the ARC port to send audio from your source device to your audio/video receiver
- OSD for system configuration settings and information display
- Switching between HDMI input sources via front panel pushbuttons, IR remote control and RS-232 commands
- EDID Expert™ – selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolution across different screens
- Built-in bi-directional RS-232 serial control port for high-end system control
- HDMI audio can be extracted to stereo audio and digital audio (optical/coaxial) outputs
- Supports 5.1 channel audio output
- Supports Consumer Electronic Control (CEC)
- Manufacturer
- ATEN
- Part number
- VS482B
- Condition
- New
- Category
- Input & Output Devices › Switches & Hubs
Overview
The ATEN VS482B Switch is an ideal solution for application requiring superior video resolution of True 4K when connecting 4 HDMI A/V sources to 2 HDMI displays. Complying with HDMI 2.0 standards, the switch’s Audio Return Channel (ARC) function allows users to send audio without having to attach a separate audio cable.
Furthermore, the VS482B offers switching methods between HDMI sources by front panel pushbuttons, IR remote control and RS-232 commands, enabling users to effortlessly select desired input. Equipped with EDID Expert™, the VS482B benefits users with optimum EDID settings for smooth power-up and highest-quality display across different screens. Featuring above functionalities provides you a practical solution for auditorium, home theater, meeting rooms, trade shows, shopping centers, and more.
Specifications
| Video port type | HDMI |
|---|---|
| HDMI ports quantity | 6 |
| HDMI in | 4 |
| Number of HDMI outputs | 2 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
| Material | Metal |
|---|---|
| Product colour | Black |
| HDCP | Yes |
| Maximum refresh rate | 60 Hz |
| Maximum operating distance | 5 m |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| Input impedance | 100 Ω |
| Output impedance | 100 Ω |
| Width | 158.8 mm |
|---|---|
| Depth | 437.2 mm |
| Height | 440 mm |
| Weight | 21.6 kg |
| Quantity per pack | 1 pc(s) |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
