ATEN VS172 video splitter DVI 3x DVI-D
Part number VS172
2PORT DVI DUAL LINK SPLITTER + AUDIO/RS2
- Displays DVI audio/video to multiple DVI-compatible monitors or projectors
- Superior video quality - up to 2560 x 1600 @ 60 Hz including 2K-resolution (2048 x 2048 @ 60 Hz)
- Cascadable to 3 levels – provides up to 8 video signals
- Audio enabled
- Features RS-232 serial port for command controls
- RS-232 Chain Control – use RS-232 commands to control cascaded devices via a DVI Cable
- EDID Expert – selects the optimum EDID settings via RS-232
- Note:
- * The VS172 AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)
- ** HDCP is not supported.
- Manufacturer
- ATEN
- Part number
- VS172
- Condition
- New
- Category
- Audio/Video Devices › Home Stereo/Theater Equipment
- 1GPA category
- Hardware
Overview
The VS172 2-Port DVI Dual Link Splitter with Audio combines DVI quality video and audio, taking signals from an audio/ video source and replicating them to two audio/video outputs. This video splitter uses dual link technology, which offers high bandwidth capacity for added transmission power and faster refresh rates, thereby providing better video quality of viewing resolutions up to 2560 x 1600.
Specifications
| Video port type | DVI |
|---|---|
| Video in | DVI-D DL |
| Video out | 3x DVI-D |
| Video ports quantity | 3 |
| Audio ports quantity | 3 |
| Serial ports quantity | 1 |
| DC-in jack | Yes |
| Product colour | Black |
|---|---|
| Housing material | Metal |
| Maximum resolution | 2560 x 1600 pixels |
| Maximum operating distance | 5 m |
| Power LED | Yes |
| AC input voltage | 5.3 V |
|---|---|
| Power consumption (typical) | 3.1 W |
| Dimensions (WxDxH) | 88 x 210 x 55.5 mm |
|---|---|
| Weight | 680 g |
| Packaging content | RoHS |
|---|
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Audio input | 3.5mm |
|---|---|
| Audio output | 3.5mm |
