ATEN VE813A AV extender AV transmitter & receiver Black

Part number VE813A

HDMI HDBASET EXTENDER WITH USB2.0 UP TO 330FT.

Implements HDBaseT extension technology using only one Cat 5e/6/6a cable that connects the transmitter and receiver
Anti-jamming – high quality video transmissions via HDBaseT technology that resists signal interference
Supports Dolby True HD and DTS HD Master Audio
ExtremeUSB® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
USB 2.0 Support* – connects devices such as keyboard, mouse, audio, flash drive, printer, touch panel, USB 1.1 web cameras and other USB devices which require moderate amounts of bandwidth
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
Works with all major operating systems: Windows®, OS X®, and Linux®
Rack-mountable
*Note: The VE813A supports a maximum combined USB transfer rate of 40 Mbps for attached USB devices

Manufacturer: ATEN
Part number: VE813A
Condition: New
Category: Input & Output Devices › Switches & Hubs

Overview

The VE813A HDMI HDBaseT Extender is an HDMI and USB Extender that supports HDBaseT and patented ExtremeUSB® technology. The VE813A can extend HDMI and USB 2.0 signal up to 100 meters from the HDMI source using a single Ethernet cable. The VE813A supports HDMI features such as 3D, Deep Color, 4K, CEC and HDCP. It is equipped with USB connectors that provide touch panel control and file transfer functionality. The extender is also great for synchronizing files and folders between portable and desktop computers. The superior display capability makes VE813A ideal for medical imaging and digital signage.

Specifications

Features
Type	AV transmitter & receiver
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Maximum transfer distance	100 m
LED indicators	Yes
Supported video modes	1080p, 2160p
Bandwidth	10.2 Gbit/s
Bandwidth	340 MHz
HDCP	Yes
Material	Metal
3D	Yes
Consumer Electronics Control (CEC) support	Yes
Impedance	100 Ω
Product colour	Black

Ports & interfaces
Connectivity technology	Wired
RJ-45 input ports	1
RJ-45 output ports	1
Number of HDMI outputs	1
USB ports quantity	4
USB version	2.0
USB connector type	USB Type-A, USB Type-B
DC-in jack	Yes

Power
Operating voltage (transmitter)	5 V
Operating voltage (receiver)	5 V
Power consumption (typical)	5.75 W
Power consumption (receiver) (max)	13.25 W

Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%

Weight & dimensions
Dimensions (WxDxH)	117.9 x 182 x 28.7 mm
Weight	1.23 kg

Packaging content
AC adapter included	Yes
Cables included	HDMI, USB
Mounting kit	Yes

Logistics data
Products per master (outer) case	5 pc(s)
