ATEN VE601T AV extender AV transmitter Black
Part number VE601T
DVI HDBASET-LITE TRANSMITTER (1920 X 1080) UP TO 230FT / 70M
- HDBaseT Connectivity – extends a DVI 1080p connection up to 70 meters via a single Cat 6a/ATEN 2L-2910 Cat 6 cable
- DVI (3D, Deep color); HDCP 1.4 compliant
- Superior video quality –1920 x 1200@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m(Cat 5e/6) / 70m (Cat 6a)
- HDBaseT Anti-Jamming – resists signal interference during video transmission using HDBaseT technology
- Plug-and-play
- Rack-mountable
- Manufacturer
- ATEN
- Part number
- VE601T
- Condition
- New
- Category
- Input & Output Devices › Switches & Hubs
Overview
The VE601T DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to mention slip-resistant DC Jack lock mechanism, the VE601 can be installed nearly anywhere while ensuring peace of mind with its unerring reliability.
* Compatible HDBaseT Receiver Units: VE601R, VE801R
Specifications
| Type | AV transmitter |
|---|---|
| Maximum resolution | 1920 x 1200 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 70 m |
| Supported video modes | 1080p |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| Bandwidth | 10.2 Gbit/s |
| Bandwidth | 340 MHz |
| Cable length | 1.8 m |
| Resolution | 1920 x 1200 pixels |
| Power | 1.85 W |
| HDCP | Yes |
| Material | Metal |
| 3D | Yes |
| Rack mounting | Yes |
| Impedance | 100 Ω |
| Product colour | Black |
| Compatible products | VE601R, VE801R |
| Ethernet LAN | Yes |
|---|---|
| DVI input ports | 1 |
| Video in | DVI-D Female |
| DC-in jack | Yes |
| Operating voltage | 5 V |
|---|---|
| Power consumption (typical) | 1.85 W |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Transmitter dimensions (WxDxH) | 87 x 103 x 30 mm |
|---|---|
| Transmitter weight | 250 g |
| Connector type | DC Jack with locking |
|---|---|
| Number of connectors | 1 |
| Quantity | 1 |
| Frequency | 340 MHz |
