ATEN

ATEN US221A computer data switch

Part number US221A

US221 ALLOWS 2 COMPUTERS TO SHARE THE SAME USB PERIPHERAL UNDER THE FOUNDATION O

Enables two computers to share a single USB peripheral device
Simple port selection via pushbuttons, configuration utility, or Auto Switch function
Auto Switch Function - no need for print server
USB 2.0 compliant
Supports transfer rates up to 480 Mbps
Multiplatform support - Windows and Mac
LED indicators display port focus
Overcurrent protection
Bus-powered
Hot pluggable
Buzzer indicates switching between computers
Supports multifunction printers

Manufacturer: ATEN
Part number: US221A
Condition: New
Category: Input & Output Devices › Switches & Hubs

Overview

The US221A is a 2-port USB 2.0 Peripheral Switch that allows up to 2 computers to share the use of a single USB peripheral device (such as a printer, scanner, mass storage drive, etc.) on a one-at-a-time basis.

The peripheral focus can be given to a computer manually by using pushbuttons on the switch, using the software-based configuration utility, or by the Auto Switch function.

Compatible with both Windows and Mac, and with multifunction printer support, the US221A is the ideal way to share the latest USB 2.0 peripherals in a multimedia office environment.

Specifications

Ports & interfaces
USB 2.0 ports quantity	3

Performance
Maximum data transfer rate	0.48 Gbit/s
LED indicators	Yes
Over current protection	Yes
Hot-Plug support	Yes
Product colour	Black, Silver
Housing material	Plastic

Operational conditions
Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%

Weight & dimensions
Width	65.8 mm
Depth	71.8 mm
Height	24.4 mm
Weight	54 g

Packaging content
Cables included	USB
Quick start guide	Yes

Logistics data
Quantity per pack	1 pc(s)
