ATEN CS1716I KVM switch Rack mounting Black
Part number CS1716I
16PORT 1U USB/PS2 KVM OVER IP
- Rack mounting 1U Black
- Number of computers controlled: 16
- 2048 x 1536 pixels
- Housing material: Metal
- 11 W
- Manufacturer
- ATEN
- Part number
- CS1716I
- Condition
- New
- Category
- Input & Output Devices › Switches & Hubs
- 1GPA category
- Hardware
Overview
Features
Management
- Convenient computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menus
- Up to 32 concurrent logins
- Multilanguage web UI support featuring a tree-structured local and remote OSD
- Adjustable video quality for flexible adaptation to diverse network environments
- Auto Scan feature for monitoring user-selected computers
- Broadcast mode; operations simultaneously performed on all selected computers (software installation, system-wide shutdown, etc.).
- Firmware upgradable
- Backup and restore configuration and user account settings
- Event logging
- Enable/disable browser access
- IPv6 capable
Ease-to-Use Interface
- Browser-based and AP GUIs, together with a menu-driven OSD for the local console, provide a powerful, intuitive, user-friendly, multilanguage interface to minimize user training time and increase productivity
- Multiplatform client support (windows, Mac OS X, Linux, Sun)
- Multibrowser support (IE, Mozilla, Firefox, Safari, Opera, Netscape)
- Port names automatically reconfigured when station sequence is changed
- Panel array mode enables user to monitor multiple servers from single screen at the same time - each selected server's video output appears in a separate panel - users can easily select the number of panels to view
- Windows client and Java client software support; Java client works with all operating systems
Advanced Security
- Secure keyboard/mouse/video transmission via RC4 128 bit encryption
- 128 bit SSL browser access
- Two level password security - up to 64 user accounts with separate profiles for each
- External (Remote) authentication support: RADIUS, LDAP, LDAPS, MS Active Directory
- Support for IP/MAC Filter
- Local and remote access logged and authenticated
Virtual Remote Desktop
- Resizable remote desktop window
- Message board allows logged in users to communicate with each other, and allows a user to take exclusive control of the KVM functions
Specifications
| Number of computers controlled | 16 |
|---|---|
| DC-in jack | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Security algorithms | 802.1x RADIUS, SSL/TLS |
| Maximum resolution | 2048 x 1536 pixels |
|---|---|
| Scan interval | 255 s |
| Plug and Play | Yes |
| Number of users | 32 user(s) |
| Rack mounting | Yes |
|---|---|
| Rack capacity | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Built-in display | No |
|---|
| Power consumption (typical) | 11 W |
|---|---|
| USB powered | No |
| Compliance certificates | RoHS |
|---|
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Width | 160 mm |
|---|---|
| Depth | 433 mm |
| Height | 44 mm |
| Weight | 3 kg |
| Cables included | KVM |
|---|---|
| Manual | Yes |
| AC adapter included | Yes |
| Connectivity technology | Wired |
|---|---|
| I/O ports | 1 x SPHD-18 M 16 x SPHD-17 F 1 x DB-25 M 1 x DC In 1 x RJ-45 F 1 x RJ-11 1 x USB1.1 A |
| Dimensions (WxDxH) | 160 x 433 x 44 mm |
| Ports quantity | 16 |
| Compatible operating systems | Windows, Mac OS X, Linux, Sun |
| Power requirements | 5.3VDC |
| Colour depth | 24 bit |
| Browser supported | IE, Mozilla, Firefox, Safari, Opera, Netscape |
