ATEN

ATEN CS1188D4 KVM switch Rack mounting Black

Part number CS1188D4

8PORT USB DVI SINGLE DISPLAY PP4.0 SECURE KVM

  • Compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) security requirements
  • Always-on chassis intrusion detection – renders the ATEN PSD PP v4.0 Secure KVM Switch series inoperable when physical tampering is detected
  • Configurable Device Filtration – supports administrative configuration to filter USB HID devices
  • Port selection via pushbuttons / Remote Port Selector (RPS) only to enhance security
Manufacturer
ATEN
Part number
CS1188D4
Condition
New
Category
Input & Output Devices › Switches & Hubs
1GPA category
Hardware

Overview

ATEN PSD PP v4.0 Secure KVM Switch CS1188D4 is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1188D4 is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).

ATEN PSD PP v4.0 Secure KVM Switch CS1188D4 provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, and speaker set between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.

To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1188D4 only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi – layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1188D4 ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.

Specifications

Ports & interfaces
Number of computers controlled8
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-I
DVI-I ports quantity8
USB 2.0 Type-B ports quantity8
Console portsDVI-I, USB A
Console USB ports quantity2
Console DVI-I ports quantity1
USB connector typeUSB Type-A, USB Type-B
Audio connectionsYes
Headphone outputs9
RJ-11 ports quantity1
Performance
HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
Video bandwidth30 Hz
Design
Rack mountingYes
Product colourBlack
Housing materialMetal
LED indicatorsYes
Push buttonYes
Display
Built-in displayNo
Power
Power sourceAC
Input voltage100 - 240 V
AC input frequency50/60 Hz
Input current1 A
Power consumption (typical)11 W
Sustainability
Compliance certificatesRoHS
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width432.4 mm
Depth204.9 mm
Height65.5 mm
Weight2.95 kg
Packaging content
Cables includedAC
ManualYes

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
