Overview
ROG Strix XG32UCG
Utility Redefined
Elevate your gaming experience with the ROG Strix XG32UCG, meticulously crafted for utility and performance. Immerse yourself with Frame Rate Boost, allowing the monitor to easily switch via hotkey to a 1080p 320Hz mode for esports ready performance and lightning-fast 1ms response time. Conquer challenges effortlessly with AI-powered features, and enhance your connectivity options with the inclusion of a versatile Type-C connection, ensuring you stay ahead while enjoying the convenience of modern connectivity.
Specifications
Display
| Display diagonal | 80 cm (31.5") |
|---|
| Display resolution | 3840 x 2160 pixels |
|---|
| HD type | 4K Ultra HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Display technology | LCD |
|---|
| Panel type | Fast IPS |
|---|
| Touchscreen | No |
|---|
| Display brightness (peak) | 400 cd/m² |
|---|
| Display brightness (typical) | 350 cd/m² |
|---|
| Response time | 1 ms |
|---|
| Response time measurement type | GTG (Gray to Gray) |
|---|
| Anti-glare screen | Yes |
|---|
| Screen shape | Flat |
|---|
| Contrast ratio (typical) | 1000:1 |
|---|
| Maximum refresh rate | 160 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 1.073 billion colours |
|---|
| Pixel pitch | 0.182 x 0.182 mm |
|---|
| Viewable size, horizontal | 69.8 cm |
|---|
| Viewable size, vertical | 39.3 cm |
|---|
| Digital horizontal frequency | 24 - 380 kHz |
|---|
| Digital vertical frequency | 48 - 160 Hz |
|---|
| Display diagonal (metric) | 80 cm |
|---|
| High Dynamic Range (HDR) supported | Yes |
|---|
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
|---|
| Colour gamut standard | DCI-P3 |
|---|
| Colour gamut | 95% |
|---|
| DCI-P3 coverage | 95% |
|---|
Performance
| NVIDIA G-SYNC | Yes |
|---|
| NVIDIA G-SYNC type | G-SYNC Compatible |
|---|
| AMD FreeSync | Yes |
|---|
| AMD FreeSync type | FreeSync Premium |
|---|
| VESA Adaptive Sync support | Yes |
|---|
| Flicker-free technology | Yes |
|---|
| Low Blue Light technology | Yes |
|---|
| Game mode | Yes |
|---|
Multimedia
| Built-in speaker(s) | No |
|---|
| Built-in camera | No |
|---|
Design
| Market positioning | Gaming |
|---|
| Product colour | Black |
|---|
| Feet colour | Black |
|---|
Ports & interfaces
| I/O ports | DisplayPort 1.2 N/A;DisplayPort 1.4x 1 (HBR3);DisplayPort 2.1N/A;HDMI (v1.4)N/A;HDMI (v2.0)N/A;HDMI (v2.1)x 1 (FRL);Micro HDMIN/A;USB-Cx 1 (DP Alt Mode);D-SubN/A;DVIN/A;Dual-Link DVIN/A;Earphone jack : Yes;USB Hub : N/A;USB 3.0 (Signal)N/A;USB-C Power Delivery : 15W;SPDIF out (Optical Digital Audio Out):N/A |
|---|
| Built-in USB hub | Yes |
|---|
| USB Type-C downstream ports quantity | 1 |
|---|
| USB Type-C DisplayPort Alternate Mode | Yes |
|---|
| USB Power Delivery (USB PD) | Yes |
|---|
| USB Power Delivery up to | 15 W |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 1 |
|---|
| HDMI version | 2.1 |
|---|
| DisplayPorts quantity | 1 |
|---|
| DisplayPort version | 1.2 |
|---|
| Headphone out | Yes |
|---|
| Headphone outputs | 1 |
|---|
| HDCP | Yes |
|---|
| HDCP version | 2.3 |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 100 x 100 mm |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Height adjustment | Yes |
|---|
| Adjustable height (max) | 11 cm |
|---|
| Swivelling | Yes |
|---|
| Swivel angle range | -25 - 25° |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | -5 - 20° |
|---|
Power
| Energy efficiency class (SDR) | F |
|---|
| Energy efficiency class (HDR) | G |
|---|
| Energy consumption (SDR) per 1000 hours | 32 kWh |
|---|
| Energy consumption (HDR) per 1000 hours | 45 kWh |
|---|
| Power consumption (typical) | 30 W |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| Power consumption (off) | 0.3 W |
|---|
| Power consumption (PowerSave) | 0.5 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50/60 Hz |
|---|
| Power supply type | Internal |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (with stand) | 717 mm |
|---|
| Depth (with stand) | 246 mm |
|---|
| Height (with stand) | 574 mm |
|---|
| Weight (with stand) | 9.9 kg |
|---|
| Width (without stand) | 717 mm |
|---|
| Depth (without stand) | 82 mm |
|---|
| Height (without stand) | 430 mm |
|---|
| Weight (without stand) | 6.6 kg |
|---|
Packaging data
| Package width | 900 mm |
|---|
| Package depth | 224 mm |
|---|
| Package height | 526 mm |
|---|
| Package weight | 12.1 kg |
|---|
| Package type | Box |
|---|
Sustainability
| Sustainability certificates | Forest Stewardship Council (FSC) Mix |
|---|
Other features
| Display viewable area (HxV) | 698.112 x 392.688 mm |
|---|
Technical details
| Native refresh rate | 60 Hz |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
