ASUS ThunderboltEX 5 interface cards/adapter Internal Mini DisplayPort, PCIe, USB 2.0, Thunderbolt 5
Part number THUNDERBOLTEX 5
ASUS THUNDERBOLTEX 5 EXPANSION CARD DUAL THUNDERBOLT 5 USB-C
- Intel® certified Thunderbolt™ 5 add-on card
- Dual USB Type-C® ports support up to 130 watts total of fast charging, and up to 96W for one device
- Up to five Thunderbolt™ devices can be daisy-chained
- Up to 120 Gbps of bandwidth for superfast data transfers and video output
- DisplayPort™ 2.1 port supports up to three 8K 60 Hz displays with DSC
- Manufacturer
- ASUS
- Part number
- THUNDERBOLTEX 5
- Condition
- New
- Category
- Storage Devices › Solid State Disks
- 1GPA category
- Hardware
Overview
ASUS ThunderboltEX 5 Expansion Card : Dual Thunderbolt™ 5 USB‑C ports, DisplayPort™ 2.1, PCIe 4.0 x4 Interface
Experience Lightning-Fast Speed and Versatile Connectivity
The ASUS ThunderboltEX 5 card offers up to 120 Gbps of Thunderbolt™ 5 bandwidth, support for DisplayPort™ 2.1 with a compatible GPU, USB4® compatibility, plus support for up to five Thunderbolt™ devices in a daisy-chain and up to 130 total watts of fast charging.
Seamless Dual-PC Sharing with Thunderbolt™ Share
Experience a revolutionary way to interact with two PCs using Thunderbolt™ Share—the ultrafast connectivity solution that transforms your dual-PC setup. Seamlessly share screens, keyboards, mice, storage and files between two computers, with the unparalleled speed of Thunderbolt™ technology.
*A certified Thunderbolt™ or USB4® cable is required to meet minimum bandwidth requirements. Cable not included.
One Cable, Multiple Devices
Simplify your setup by daisy-chaining multiple Thunderbolt™ devices to one Thunderbolt™ 5 port.
Optimized for Blistering Data Transfer Speeds
Specifications
| Host interface | PCIe |
|---|---|
| Output interface | Mini DisplayPort, PCIe, USB 2.0, Thunderbolt 5 |
| Expansion card standard | PCIe 4.0 |
| Internal | Yes |
|---|---|
| Product colour | Multicolour |
| Purpose | PC |
| Chipset | Intel JHL9580 Thunderbolt 5 Controller |
|---|---|
| Data transfer rate (max) | 120 Gbit/s |
| Windows operating systems supported | Windows 11 x64 |
|---|
| Width | 88.9 mm |
|---|---|
| Depth | 119.5 mm |
| Quantity per pack | 1 pc(s) |
|---|---|
| Package type | Box |
| Maximum resolution | 7680 x 4320 pixels |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
