ASUS ThunderboltEX 4 interface cards/adapter Internal Mini DisplayPort, PCIe, Thunderbolt, USB 2.0, USB 3.2 Gen 2 (3.1 Gen 2)
Part number THUNDERBOLTEX 4
ASUS THUNDERBOLTEX 4 W INTEL THUNDERBOLT 4 JHL 8540 CONTROLLE
Intel®-certified Thunderbolt™ 4 add-on card
40 Gbps bi-directional bandwidth for superfast data transfers and video output
Dual Thunderbolt™ 4 ports (USB-C®), with support for up to five Thunderbolt devices in a daisy chain
DisplayPort™ 1.4 for 8K Ultra HD support
Manufacturer
ASUS
Part number
THUNDERBOLTEX 4
Condition
New
Category
Input & Output Devices › Usb & Firewire Conn
1GPA category
Hardware
Overview
Enable blisteringly fast speeds and any-way-up connectivity
ASUS ThunderboltEX 4 is a Thunderbolt™ 4 add-on card that offers 40 Gbps bi-directional bandwidth, USB4™ device compatibility, and DisplayPort™ 1.4. It supports up to five Thunderbolt devices in a daisy chain and enables up to 100-watt USB-C® charging for laptops.
Specifications
Ports & interfaces
Host interface
PCIe
Output interface
Mini DisplayPort, PCIe, Thunderbolt, USB 2.0, USB 3.2 Gen 2 (3.1 Gen 2)
Expansion card standard
PCIe 3.0
USB 2.0 ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
Design
Internal
Yes
Product colour
Black
Purpose
PC
Features
Chipset
Intel Thunderbolt 4 JHL8540
Data transfer rate (max)
40 Gbit/s
Plug and Play
Yes
System requirements
Windows operating systems supported
Windows 10 x64
Weight & dimensions
Width
117.7 mm
Depth
180.5 mm
Packaging data
Quantity
1
Cables included
Mini DisplayPort, Thunderbolt, USB
Drivers included
Yes
Manual
Yes
Package type
Box
Logistics data
Harmonized System (HS) code
84733020
Other features
Maximum resolution
7680 x 4320 pixels
Compatibility
ASUS Intel 500
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
