ASUS
ASUS ROG STRIX X870E-A GAMING WIFI7 NEO AMD X870E Socket AM5 ATX
Part number ROG STRIX X870E-A GAMING WIFI7 NEO
ASUS ROG STRIX X870E-A GAMING WIFI7 NEO, AMD ATX MOTHERBOARD, 16+2+2 POWER STAGE
AMD Socket AM5 AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series PC ATX AMD X870E 7.1 channels DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB HDD & SSD SATA III, M.2 RAID support Number of storage drives supported: 8 BIOS type: UEFI AMI 64 Mbit Clear CMOS button 5 Gigabit Ethernet Wi-Fi Wi-Fi 7 (802.11be) Bluetooth 5.4
Manufacturer ASUS
Part number ROG STRIX X870E-A GAMING WIFI7 NEO
Condition New
Category System Components › Motherboards 1GPA category Hardware
Manufacturer MSRP
$469.99
On 1GPA? Sign in to see your contract price.
Stock and final pricing are confirmed by your rep on the quote. Catalog dated September 30, 2026.
Overview
ROG STRIX X870E-A gaming wifi7 Neo
Elevate your build with the ROG Strix X870E-A Gaming WiFi7 Neo, featuring a sleek white aesthetic and a design that maximizes the performance of AMD Ryzen™ 9000 Series processors. PCIe® 5.0, ASUS AI features including AI Cache Boost and ASUS AI Advisor—and exclusive memory technologies such as NitroPath DRAM Technology, DIMM Fit Pro, and AEMP—simplify setup and deliver optimized DDR5 performance. High-speed connectivity is boosted by dual USB4® Type-C ports, WiFi 7, and Realtek® 5G Ethernet, while enhanced M.2 cooling helps ensure stability for demanding workloads. It is the ultimate blend of style and performance.
Specifications
Processor
Processor manufacturer AMD Processor socket Socket AM5 Compatible processor series AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Memory
Supported memory types DDR5-SDRAM Number of memory slots 4 Memory slots type DIMM Memory channels Dual-channel ECC сompatibility ECC & Non-ECC Supported memory clock speed (max) 9600 MHz Maximum internal memory 256 GB Unbuffered memory Yes
Storage controllers
Supported storage drive types HDD & SSD Supported storage drive interfaces SATA III, M.2 Number of HDDs supported 4 Number of storage drives supported 8 RAID support Yes RAID levels 0, 1, 5, 10
Graphics
Parallel processing technology support Not supported
Internal I/O
USB 2.0 connectors 3 USB 3.2 Gen 1 (3.1 Gen 1) connectors 2 USB 3.2 Gen 2x2 connectors 1 Number of SATA III connectors 4 Front panel audio connector Yes ATX Power connector (24-pin) Yes CPU fan connector Yes Number of CPU fan connectors 1 Number of chassis fan connectors 5 Chassis intrusion connector Yes EPS power connector (8-pin) Yes 12V power connector Yes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 5 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 USB4 Gen 3x2 ports quantity 2 Ethernet LAN (RJ-45) ports 1 HDMI ports quantity 1 Microphone in Yes S/PDIF out port Yes WiFi-AP antenna jack 1
Network
Ethernet LAN Yes Ethernet interface type 5 Gigabit Ethernet Wi-Fi Yes Top Wi-Fi standard Wi-Fi 7 (802.11be) Wi-Fi standards Wi-Fi 7 (802.11be) WLAN controller model MediaTek MT7925 Bluetooth Yes Bluetooth version 5.4
Features
Motherboard chipset AMD X870E Audio output channels 7.1 channels Product colour Multicolour Component for PC Motherboard form factor ATX Motherboard chipset family AMD Windows operating systems supported Windows 11
Expansion slots
PCI Express x16 (Gen 4.x) slots 1 PCI Express x16 (Gen 5.x) slots 1 Number of M.2 (M) slots 4 1st M.2 largest key size 2280 1st M.2 highest PCI Express generation 5.0 2nd M.2 largest key size 2260 2nd M.2 highest PCI Express generation 5.0 3rd M.2 largest key size 2242 3rd M.2 highest PCI Express generation 5.0 4th M.2 largest key size 22110 4th M.2 highest PCI Express generation 5.0
BIOS
BIOS type UEFI AMI BIOS memory size 64 Mbit Clear CMOS button Yes
Packaging data
Package width 353 mm Package depth 273 mm Package height 68 mm Package weight 2.7 kg
Weight & dimensions
Width 305 mm Depth 244 mm Height 50 mm
Other features
Weight 1.9 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
