ASUS ROG ASTRAL GEFORCE RTX 5080 16GB GDDR7 WHITE OC EDITION
NVIDIA GeForce RTX 5080 16 GB GDDR7
7680 x 4320 pixels 256 bit 30 Gbit/s PCI Express 5.0
HDMI ports quantity: 2 DisplayPorts quantity: 3
DirectX version: 12 Ultimate OpenGL version: 4.6
1x 16-pin
Manufacturer
ASUS
Part number
ROG-ASTRAL-RTX5080-O16G-WHITE
Condition
New
Category
System Components › Video & Capture Card
1GPA category
Hardware
Overview
The Final Frontier
The new ROG Astral family was inspired by the limitless expanse and beauty of the cosmos, and it is a testament to an unending dedication to exploring and defining new frontiers. In that spirit, the ROG Astral GeForce RTX 5080 White Edition introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations – amplified by an eye-catching die-cast frame and metal GPU bracket – combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
Specifications
Processor
CUDA
Yes
CUDA cores
10752
Graphics processor family
NVIDIA
Graphics processor
GeForce RTX 5080
Processor boost clock speed
2760 MHz
Processor frequency (OC mode)
2790 MHz
Maximum resolution
7680 x 4320 pixels
Parallel processing technology support
Not supported
Maximum displays per videocard
4
Memory
Discrete graphics card memory
16 GB
Graphics card memory type
GDDR7
Memory bus
256 bit
Data transfer rate
30 Gbit/s
Ports & interfaces
Interface type
PCI Express 5.0
HDMI ports quantity
2
HDMI version
2.1b
DisplayPorts quantity
3
DisplayPort version
2.1b
Performance
TV tuner integrated
No
DirectX version
12 Ultimate
OpenGL version
4.6
Virtual Reality (VR) ready
Yes
HDCP
Yes
HDCP version
2.3
Dual Link DVI
No
NVIDIA G-SYNC
Yes
NVIDIA Ansel
Yes
NPU performance up to
1801 TOPs
Design
Cooling type
Active
Cooling technology
ASUS Axial-tech
Number of fans
4 fan(s)
Form factor
Full-Height/Full-Length (FH/FL)
Number of slots
3.8
Illumination
Yes
Illumination colour
Multi
Product colour
White
Power
Minimum system power supply
850 W
Supplementary power connectors
1x 16-pin
System requirements
Windows operating systems supported
Yes
Weight & dimensions
Length
357.6 mm
Depth
76 mm
Height
149.3 mm
Packaging data
Package type
Box
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
