ASUS RNUC16GDKX76C4NU
View 1 View 2 View 3 View 4 View 5 View 6 View 7 View 8
ASUS

ASUS NUC RNUC16GDKX76C4NU Copilot+ PC Intel Core Ultra X7 358H 32 GB LPDDR5x-SDRAM 1 TB SSD Windows 11 Pro Mini PC Black

Part number RNUC16GDKX76C4NU

ASUS NUC 16 PRO FULL SYS MINI P INTEL ULTRA X7 358H 32GB LPDDR5X

  • Windows 11 Pro 64-bit
  • Intel Core Ultra X7 358H (18MB Cache)
  • 32GB (8533MHz) LPDDR5x-SDRAM & 1000GB SSD
Manufacturer
ASUS
Part number
RNUC16GDKX76C4NU
Condition
New
Category
Computer Systems › Desktop Computers
1GPA category
Hardware

Overview

Faster, Smarter, More Secure

For the AI-Driven Enterprise

The ASUS NUC 16 Pro mini PC features up to the latest Intel® Core™ Ultra X9 series 3 processor featuring Intel Arc™, delivering up to 1.5X-faster gen-on-gen 3D graphics performance, and supports up to 96GB of lightning-fast LPDDR5x memory—all while boasting incredible energy efficiency. Built-in firmware TPM 2.0 (fTPM 2.0) handles data security and management, while dual 2.5G LAN and two HDMI® ports ensure convenient connectivity. Its AI-ready performance and robust security make the NUC 16 Pro ideal for businesses.

Specifications

Processor
Processor manufacturerIntel
Processor familyIntel Core Ultra X7
Processor generationIntel® Core™ Ultra (Series 3)
Processor model358H
Processor cores16
Processor threads16
Processor boost frequency4.8 GHz
Performance cores4
Efficient cores8
Performance-core Max Turbo Frequency4.8 GHz
Efficient-core Max Turbo Frequency3.5 GHz
Performance-core base frequency1.9 GHz
Efficient-core base frequency1.5 GHz
Processor cache18 MB
Processor cache typeSmart Cache
Processor socketFCBGA2540
Processor base power25 W
Maximum turbo power80 W
Neural processor unit (NPU)
Copilot+ PCYes
Neural processor unit (NPU)Intel AI Boost
NPU performance up to50 TOPs
GPU performance up to122 TOPs
Memory
Internal memory32 GB
Internal memory typeLPDDR5x-SDRAM
Memory clock speed8533 MHz
Storage
Total storage capacity1 TB
Storage mediaSSD
Optical drive typeNo
Total SSDs capacity1 TB
Number of SSDs installed1
SSD capacity1 TB
SSD interfacePCI Express 4.0
NVMeYes
SSD form factorM.2
M.2 SSD size2280 (22 x 80 mm)
Storage optionsSupport: 128GB~8TB M.2 2280 NVMe™ PCIe® 4.0x4 SSD or 128GB~8TB M.2 2280 NVMe™ PCIe® 5.0x4 SSD, Included: 1TB M.2 2280 NVMe™ PCIe® 4.0 SSD​
Graphics
Discrete graphics cardNo
On-board graphics cardYes
Discrete graphics card modelNot available
On-board GPU manufacturerIntel
On-board graphics card familyIntel Arc Graphics
On-board graphics card modelIntel Arc Graphics
Performance
Market positioningPerformance
Product typeMini PC
Built-in speaker(s)No
Network
Ethernet LANYes
Ethernet LAN data rates2500 Mbit/s
LAN controllerIntel I226-V
Wi-FiYes
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standardsWi-Fi 7 (802.11be)
WLAN controller manufacturerIntel
WLAN controller modelIntel Wi-Fi 7 BE211
BluetoothYes
Bluetooth version6.0
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Intel® Thunderbolt 4Yes
Thunderbolt 4 ports quantity2
HDMI ports quantity2
HDMI version2.1
Ethernet LAN (RJ-45) ports2
DC-in jackYes
Power
Power supply150 W
Design
Chassis typeMini PC
Colour nameBlack
Cable lock slotYes
Cable lock slot typeKensington
Product colourBlack
Software
Operating system architecture64-bit
Operating system installedWindows 11 Pro
Display
Display includedNo
Weight & dimensions
Width144 mm
Depth117 mm
Height42 mm
Weight750 g

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
