ASUS NUC 16 PRO BAREBONE MINI P INTEL 3 CORE ULTRA 7 356DDR5 RAM
Powered by up to Intel Core Ultra X9 CPU, Arc B390 GPU, and NPU 5, it enables AI-accelerated hybrid computing, delivering up to 180 TOPS for real-time Edge AI
Up to 96 GB LPDDR5x 9600 MT/s with 20% faster speed and 50% lower power, plus dual-fan cooling for sustained peak performance
Wi-Fi 7, Bluetooth 6.0, and dual 2.5G LAN provide low-latency, redundant, and secure connectivity for enterprise and Edge AI
Built-in firmware TPM 2.0 provides enterprise-grade data protection and compliance, enabling IT professionals to securely manage devices and scale services with ease
Compact 5×4 chassis with Tool-less 2.0 design supports dual M.2 Gen5/Gen4 SSDs, maximizing airflow, flexibility, and performance
Rugged modular build with long-life availability and rich I/O, including RS-232 and PCIe x1, for POS, IoT, and industrial deployment
Manufacturer
ASUS
Part number
RNUC16GDKU76000U
Condition
New
Category
Computer Systems › Barebones Systems
1GPA category
Hardware
Overview
Faster, Smarter, More Secure For the AI-Driven Enterprise
The ASUS NUC 16 Pro mini PC features up to the latest Intel® Core™ Ultra X9 series 3 processor featuring Intel Arc™, delivering up to 1.5X-faster gen-on-gen 3D graphics performance, and supports up to 96GB of lightning-fast LPDDR5x memory—all while boasting incredible energy efficiency. Built-in firmware TPM 2.0 (fTPM 2.0) handles data security and management, while dual 2.5G LAN and two HDMI® ports ensure convenient connectivity. Its AI-ready performance and robust security make the NUC 16 Pro ideal for businesses.
Specifications
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 7
Processor generation
Intel® Core™ Ultra (Series 3)
Processor model
356H
Processor cores
16
Processor threads
16
Processor boost frequency
4.7 GHz
Performance cores
4
Efficient cores
8
Low Power Efficient-cores
4
Performance-core Max Turbo Frequency
4.7 GHz
Efficient-core Max Turbo Frequency
3.5 GHz
Low Power Efficient-core Max Turbo Frequency
3.3 GHz
Performance-core base frequency
1.9 GHz
Efficient-core base frequency
1.5 GHz
Low Power Efficient-core Base Frequency
1500 MHz
Built-in processor
Yes
Processor cache
18 MB
Memory
Internal memory installed
No
Memory slots type
SO-DIMM
Number of memory slots
2
Maximum internal memory
128 GB
Memory channels
Dual-channel
Storage
Storage drives installed
No
Supported storage drive types
SSD
Storage drive sizes supported
M.2
SSD form factor
M.2
Storage drive interface
PCI Express
Number of storage drives supported
2
Maximum storage capacity
8 TB
Graphics
On-board graphics card
Yes
Graphics card family
Intel
On-board graphics card model
Intel® Graphics
Performance
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Audio
Built-in speaker(s)
No
Network
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
WLAN controller model
Intel Wi-Fi 7 BE211
Ethernet LAN
Yes
Wi-Fi
Yes
LAN controller
Intel I226-V
Bluetooth
Yes
Bluetooth version
6.0
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
HDMI ports quantity
2
HDMI version
2.1
Ethernet LAN (RJ-45) ports
2
Thunderbolt 4 ports quantity
2
DC-in jack
Yes
Design
Product colour
Black
Cooling type
Active
On/off switch
Yes
Cable lock slot
Yes
Cable lock slot type
Kensington
VESA mounting
Yes
Product type
Mini PC barebone
Power
Power supply type
External AC adapter
Power supply
150 W
AC adapter output voltage
7.7 V
AC adapter output current
19.5 A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 60 °C
Operating relative humidity (H-H)
0 - 92%
Weight & dimensions
Width
144 mm
Depth
117 mm
Height
42 mm
Weight
730 g
