ASUS NUC RNUC15CRKU5063CU Intel Core Ultra 5 225H 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black
Part number RNUC15CRKU5063CU
ASUS NUC 15 PRO SLIM FULL SYSTE INTEL SERIES 2 CORE ULTRA 5 225H 16
Windows 11 Pro 64-bit
Intel Core Ultra 5 225H (18MB Cache)
16GB DDR5-SDRAM & 512GB SSD
Manufacturer
ASUS
Part number
RNUC15CRKU5063CU
Condition
New
Category
Computer Systems › Desktop Computers
1GPA category
Hardware
Overview
ASUS NUC 15 Pro
Best Compact Choice for the AI-Driven Future.
Experience the future of computing with ASUS NUC 15 Pro – a sleek mini PC that’s perfect for office and edge computing. Powered by the latest Intel® Core™ Ultra processor with DDR5 6400MHz memory and Intel Arc™ graphics, ASUS NUC 15 Pro delivers unmatched speed and efficiency in a scratch-resistance matte texture chassis
Specifications
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 5
Processor generation
Intel Core Ultra (Series 2)
Processor model
225H
Processor cores
14
Processor threads
14
Processor boost frequency
4.9 GHz
Performance cores
4
Efficient cores
8
Performance-core Max Turbo Frequency
4.9 GHz
Efficient-core Max Turbo Frequency
4.3 GHz
Performance-core base frequency
1.7 GHz
Efficient-core base frequency
1.3 GHz
Processor cache
18 MB
Processor base power
28 W
Maximum turbo power
115 W
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to
83 TOPs
NPU performance up to
13 TOPs
GPU performance up to
63 TOPs
Memory
Internal memory
16 GB
Maximum internal memory
96 GB
Internal memory type
DDR5-SDRAM
Memory slots
2x SO-DIMM
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
Intel Arc Graphics
On-board graphics card model
Intel Arc 130T
Performance
Product type
Mini PC
Network
Ethernet LAN
Yes
Ethernet LAN data rates
2500 Mbit/s
LAN controller
Intel I226-V
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
Bluetooth
Yes
Bluetooth version
5.4
Ports & interfaces
USB 2.0 ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2x2 Type-C ports quantity
1
Intel® Thunderbolt 4
Yes
Thunderbolt 4 ports quantity
2
HDMI ports quantity
2
HDMI version
2.1
Ethernet LAN (RJ-45) ports
1
Power
Power supply
120 W
Design
Chassis type
Mini PC
Colour name
Black
Placement supported
Horizontal/Vertical
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Software
Operating system architecture
64-bit
Operating system installed
Windows 11 Pro
Display
Display included
No
Weight & dimensions
Width
117 mm
Depth
112 mm
Height
36.8 mm
Weight
510 g
