ASUS NUC 13 RNUC13L3HV70000UI UCFF Black i7-1370P
Part number RNUC13L3HV70000UI
LIBERTY CANYON ASUS NUC 13 PRO INTEL CORE I7-1370P BAREBONE KIT
- No OS
- Intel Core i7-1360P (18MB Cache)
- DDR4-SDRAM (3200MHz)
- Manufacturer
- ASUS
- Part number
- RNUC13L3HV70000UI
- Condition
- New
- Category
- Computer Systems › Barebones Systems
- 1GPA category
- Hardware
Overview
Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifespan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i7 |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor model | i7-1370P |
| Processor cores | 14 |
| Processor threads | 20 |
| Processor boost frequency | 5.2 GHz |
| Performance cores | 6 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 5.2 GHz |
| Efficient-core Max Turbo Frequency | 3.9 GHz |
| Built-in processor | Yes |
| Processor cache | 24 MB |
| Memory slots type | SO-DIMM |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Supported storage drive types | HDD & SSD |
|---|---|
| Storage drive sizes supported | 2.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | M.2, Serial ATA III |
| NVMe | Yes |
| Number of storage drives supported | 2 |
| On-board graphics card | Yes |
|---|---|
| Graphics card family | Intel |
| Discrete graphics card model | Not available |
| Motherboard form factor | UCFF |
|---|---|
| Number of processors supported | 1 |
| Built-in speaker(s) | No |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 4 ports quantity | 2 |
| DC-in jack | Yes |
| PCI Express slots version | 4.0 |
|---|
| Chassis type | UCFF |
|---|---|
| Product colour | Black |
| VESA mounting | Yes |
| Product type | Mini PC barebone |
| Operating system installed | No |
|---|
| Power supply type | External AC adapter |
|---|---|
| Power supply | 120 W |
| Width | 117 mm |
|---|---|
| Depth | 112 mm |
| Height | 54 mm |
| Weight | 610 g |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
