ASUS NUC 12 RNUC12WSKI500000I Black i5-1240P
Part number RNUC12WSKI500000I
WALLSTREET CANYON INTEL I5 12TH 12 CORE W11 HOME/PRO PWR CORD SLIM
- 12th Gen Intel® Core™ i7/i5/i3 processors or Intel vPro® Enterprise with 12th Gen Intel® Core™ i7/i5 processors
- Intel® Iris® Xe graphics
- Up to 64 GB dual-channel DDR4-3200 SODIMMs
- M.2 22x80 key M slot for PCIe x4 Gen 4 NVMe SSD
- M.2 22x42 key B slot for PCIe x1 Gen 3, USB 3.2 Gen 2, USB 2.0, and SATA SSD expandability
- Support in tall chassis for third SSD with 2.5” drive capability (up to 15mm tall)
- Manufacturer
- ASUS
- Part number
- RNUC12WSKI500000I
- Condition
- New
- Category
- Computer Systems › Barebones Systems
- 1GPA category
- Hardware
Overview
Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifespan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | 12th gen Intel® Core™ i5 |
| Processor model | i5-1240P |
| Processor cores | 12 |
| Processor threads | 16 |
| Processor boost frequency | 4.4 GHz |
| Performance cores | 4 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 4.4 GHz |
| Efficient-core Max Turbo Frequency | 3.3 GHz |
| Built-in processor | Yes |
| Processor cache | 12 MB |
| ECC supported by processor | No |
| Memory slots type | SO-DIMM |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Supported storage drive types | SSD |
|---|---|
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| NVMe | Yes |
| On-board graphics card | Yes |
|---|---|
| Graphics card family | Intel |
| On-board graphics card model | Intel Iris Xe Graphics |
| Audio output channels | 2.0 channels |
|---|---|
| Audio chip | Realtek ALC269 |
| Built-in speaker(s) | No |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Serial port via internal header | No |
| Thunderbolt 4 ports quantity | 2 |
| DC-in jack | Yes |
| Product colour | Black |
|---|---|
| Cooling type | Active |
| On/off switch | Yes |
| Product type | Mini PC barebone |
| Power supply type | External AC adapter |
|---|
| Width | 117 mm |
|---|---|
| Depth | 112 mm |
| Height | 37 mm |
| Weight | 510 g |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
