ASUS ExpertCenter PRO ET500I W8-B-750 Desktop Black Intel W880 LGA 1851 (Socket V1)
Part number PRO ET500I W8-B-750
ASUS EXPERTCENTER PRO ET500I W8 TAA INTEL CORE ULTRA CPU DDR5 ECC
Ready for 2D/3D rendering with support for one NVIDIA Quadro RTX
Dual onboard 2.5GbE ethernet ports for faster high-density, high-bandwidth and low-latency
Triple M.2 for up to 32Gbps for better performance and data redundancy
Two SlimSAS ports, ready for industrial-grade NVMe storage devices
Rich I/O options including Thunderbolt 4, USB 20Gbps Type-C, USB 10Gbps Type A and USB 5Gbps for versatile connectivity
A EPEAT Bronze-certified workstation for greener environment
Independent software vendor (ISV) certification for validated reliability and compatibility with key applications
ASUS Control Center Express empowers real-time IT monitoring and management for enhanced data protection
Manufacturer
ASUS
Part number
PRO ET500I W8-B-750
Condition
New
Category
Computer Systems › Workstations
1GPA category
Hardware
Overview
ExpertCenter Pro ET500I W8 Workstation
ASUS ExpertCenter Pro ET500I W8 is a mainstream workstation that delivers professional performance and flexible expandability ideal for a range of applications from design to virtualization. Equipped with the Intel® Core™ Ultra Processors (Series 2) and ECC memory, plus support for an NVIDIA RTX™ PRO graphics card and independent software vendor (ISV) certification, ExpertCenter Pro ET500I W8 delivers the performance, reliability and guaranteed compatibility you can trust for your professional workflows.
Specifications
Processor
Built-in processor
No
Memory
Internal memory installed
No
Memory slots type
DIMM
Number of memory slots
4
Maximum internal memory
256 GB
Supported memory types
DDR5-SDRAM
Memory channels
Dual-channel
ECC
Yes
Non-ECC
No
Storage
Storage drives installed
No
Supported storage drive types
HDD & SSD
Storage drive sizes supported
M.2,2.5,3.5
SSD form factor
M.2
M.2 SSD size
2280 (22 x 80 mm)
Storage drive interface
Serial ATA III, M.2, SlimSAS
Number of storage drives supported
9
RAID levels
0, 1, 5, 10
Graphics
On-board graphics card
No
Performance
Motherboard chipset
Intel W880
Processor socket
LGA 1851 (Socket V1)
Number of processors supported
1
Compatible processor series
Intel Core Ultra (Series 2)
Audio
Built-in speaker(s)
No
Network
Ethernet LAN
Yes
Wi-Fi
No
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
6
USB4 Gen 2x2 ports quantity
2
HDMI ports quantity
1
Microphone in
Yes
Headphone outputs
1
Ethernet LAN (RJ-45) ports
2
Serial ports quantity
1
S/PDIF out port
Yes
Thunderbolt 4 ports quantity
1
Expansion slots
PCI Express x16 slots
1
PCI Express x16 (Gen 5.x) slots
2
Number of M.2 (M) slots
3
Design
Chassis type
Desktop
Product colour
Black
Cooling type
Active
On/off switch
Yes
LED indicators
Power, HDD
Product type
Workstation barebone
Power
Power supply type
Internal power supply unit
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-40 - 70 °C
Storage relative humidity (H-H)
20 - 90%
Weight & dimensions
Width
190 mm
Depth
423 mm
Height
435 mm
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
