ASUS ExpertCenter PN53-SYS735PX1TD0 AMD Ryzen™ 7 6800H 32 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black
Part number PN53-SYS735PX1TD0
EXPERTCENTER PN53-SYS735PX1TD0 MINI PC AMD RYZEN 7 6800H 32GB
Windows 11 Pro 64-bit
AMD Ryzen 7 6800H (16MB Cache, 3.2GHz)
32GB DDR5-SDRAM & 512GB SSD
Manufacturer
ASUS
Part number
PN53-SYS735PX1TD0
Condition
New
Category
Computer Systems › Desktop Computers
1GPA category
Hardware
Overview
Ultra-compact Mini PC provides flexible, comprehensive solutions
ASUS ExpertCenter PN53 is no lightweight when it comes to performance. It harnesses the power of the latest AMD Ryzen™ 6000 and 7000 Series processor combined AMD Radeon™ 600M series graphics, and can accommodate multiple storage combinations. There's also two ultrafast PCIe®Gen 4 SSD slots and DDR5 support to ensure fast boot times and rapid app loads.
Specifications
Processor
Processor manufacturer
AMD
Processor family
AMD Ryzen™ 7
Processor generation
AMD Ryzen 6000 Series
Processor model
6800H
Processor cores
8
Processor boost frequency
4.7 GHz
Processor frequency
3.2 GHz
Processor cache
16 MB
Memory
Internal memory
32 GB
Internal memory type
DDR5-SDRAM
Memory slots
2x SO-DIMM
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
AMD
On-board graphics card model
AMD Radeon 680M
Performance
Product type
Mini PC
Built-in speaker(s)
No
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Cabling technology
10/100/1000Base-T(X)
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Antenna type
2x2
Bluetooth
Yes
Bluetooth version
5.0
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB4 Gen 3x2 ports quantity
2
HDMI ports quantity
2
Ethernet LAN (RJ-45) ports
1
Combo headphone/mic port
Yes
Headphone outputs
1
DC-in jack
Yes
Power
Power supply
150 W
Design
Chassis type
Mini PC
Colour name
Black
Volume
0.6 L
Placement supported
Horizontal
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Software
Operating system architecture
64-bit
Operating system installed
Windows 11 Pro
Display
Display included
No
Audio
Audio chip
Realtek ALC3251-CG
Audio system
High Definition Audio
Weight & dimensions
Width
120 mm
Depth
130 mm
Height
58 mm
Weight
900 g
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
