ASUS ExpertCenter PB64-SYS715PETH0 Intel Core Ultra 7 265 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black
Part number PB64-SYS715PETH0
ASUS PB64 FULL SYSTEM MINI PC WITH INTEL CORE ULTRA 7 265 PROCESSOR, 16GB DDR5-5
Windows 11 Pro 64-bit
Intel Core Ultra 7 265 (30MB Cache)
16GB (5600MHz) DDR5-SDRAM & 512GB SSD
Manufacturer
ASUS
Part number
PB64-SYS715PETH0
Condition
New
Category
Computer Systems › Desktop Computers
1GPA category
Hardware
Overview
ASUS ExpertCenter PB64
Solid Reliability for Businesses
The ASUS ExpertCenter PB64 mini PC is a compact 1.35 Liter powerhouse designed for demanding computing tasks. Powered by the latest Intel® Core™Ultra processors (Series 2) with Intel® Graphics, it delivers desktop-grade performance in a small form factor. With dual PCIe Gen4 SSD slots and support for up to DDR5-6400 memory, the PB64 ensures lightning-fast data transfer. Its versatility is enhanced by configurable ports, eight USB ports, a toolless design, and triple storage options— making it an ideal solution for users who need both performance and flexibility in a mini PC
Specifications
Processor
Processor manufacturer
Intel
Processor family
Intel Core Ultra 7
Processor generation
Intel Core Ultra (Series 2)
Processor model
265
Processor cores
20
Processor threads
20
Processor boost frequency
5.3 GHz
Performance cores
8
Efficient cores
12
Efficient-core Max Turbo Frequency
4.6 GHz
Processor cache
30 MB
Processor cache type
Smart Cache
Processor socket
LGA 1851 (Socket V1)
Processor base power
65 W
Maximum turbo power
182 W
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Total processor performance up to
33 TOPs
NPU performance up to
13 TOPs
GPU performance up to
8 TOPs
Memory
Internal memory
16 GB
Maximum internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory slots
2x SO-DIMM
Memory clock speed
5600 MHz
Memory channels
Dual-channel
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
M.2 SSD size
2280 (22 x 80 mm)
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
Intel® Graphics
On-board graphics card model
Intel® Graphics
Performance
Motherboard chipset
Intel B860
Product type
Mini PC
Built-in speaker(s)
Yes
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi standards
Wi-Fi 7 (802.11be)
Bluetooth
Yes
Bluetooth version
5.4
Ports & interfaces
USB 2.0 ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB4 Gen 2x2 ports quantity
1
DisplayPorts quantity
2
DisplayPort version
1.4
Ethernet LAN (RJ-45) ports
1
Combo headphone/mic port
Yes
Headphone outputs
1
Line-out
Yes
Microphone in
Yes
Power
Power supply
120 W
Design
Chassis type
Mini PC
Colour name
Black
Cable lock slot
Yes
Cable lock slot type
Kensington
Product colour
Black
Software
Operating system architecture
64-bit
Operating system installed
Windows 11 Pro
Display
Display included
No
Weight & dimensions
Width
175 mm
Depth
175 mm
Height
44.2 mm
Weight
1.2 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
