ASUS J6412T-IM-A mini ITX
Part number J6412T-IM-A
FAN-LESS MINI-ITX INDUSTRIAL MB INTEL CELERON QUAD-CORE J6412 SO
- Fan-less mini-ITX Industrial MB with Intel Celeron® J6412 processor
- Supports 3 displays configuration by multiple interface: HDMI/DP/LVDS/eDP(optional)
- 7 years of longevity with extended product life cycles
- Advanced I/O and connectivity features
- Wide temperature range endurance: 0–60°C
- Manufacturer
- ASUS
- Part number
- J6412T-IM-A
- Condition
- New
- Category
- System Components › Motherboards
- 1GPA category
- Hardware
Overview
Fan-less thin mini-ITX motherboard for Intel Celeron® Quad-Core J6412 processor, Low-power, 2 x SO-DIMM slots, HDMI, LVDS, M.2 E Key, M.2 M Key, Mini-PCIe, 6 x COM
ASUS J6412T-IM-A is a Thin Mini-ITX industrial motherboard featuring rich I/O capabilities, advanced connectivity and flexible customization options in a smaller and thinner board that reduces chassis sizes for space-restrictive installations. Offering multiple display outputs, legacy options for industrial applications, GPIO ports, dual Intel LAN as well as rich expandability with a mini PCIe slot, M.2 E key, M.2 M key, ASUS J6412T-IM-A is an ideal choice for a wide range of embedded applications.
As the world’s No.1 motherboard brand, ASUS offers industrial motherboards with durable, industrial-grade components for reliable 24/7 operation in harsh environments and use in different vertical markets. ASUS provides a faster time-to-market with customization and motherboard modulation by leveraging over 30 years of design and innovation expertise, world-class after sales service, material supply flexibility, the ability to respond rapidly to forecast changes and long-term technical support, enabling customers to find the perfect solution to match their requirements.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Compatible processor series | Intel® Celeron® |
| Processor model | J6412 |
| Processor cores | 4 |
| Supported memory types | DDR4-SDRAM |
|---|---|
| Number of memory slots | 2 |
| Memory slots type | SO-DIMM |
| ECC сompatibility | Non-ECC |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200 MHz |
| Maximum internal memory | 32 GB |
| Maximum resolution | 4096 x 2160 pixels |
|---|
| USB 2.0 connectors | 2 |
|---|---|
| Number of SATA III connectors | 1 |
| Front panel audio connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| TPM connector | Yes |
| Serial port headers | 6 |
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Ethernet LAN | Yes |
|---|---|
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| LAN controller | Realtek RTL8111H |
| Audio chip | Realtek ALC897 |
|---|---|
| Motherboard form factor | mini ITX |
| Motherboard chipset family | Intel |
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 10 IoT Enterprise, Windows 10 x64 |
| Certification | CE, FCC, VCCI, BSMI, RCM CE-LVD |
| PCI Express x1 (Gen 3.x) slots | 1 |
|---|
| Storage temperature (T-T) | -40 - 85 °C |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Width | 170 mm |
|---|---|
| Depth | 170 mm |
