ASUS A31 PLUS WHITE ATX CASE (HIDDEN-CONNECTOR MOTHERBOARDS, 360MM RADIATORS AND
Ready for Hidden Connectors: Built for motherboards featuring hidden connectors to optimize cable management for a clutter-free setup
Broad Compatibility: The A31 PLUS supports up to 360mm radiators combined with fans of up to 80mm thick, plus graphics cards up to 380mm in length and CPU air coolers with heights of up to 165mm
Panoramic Design: Tempered glass panels on the front and side offer unobstructed views of the main chamber
8° Angled Base: The golden angle combines functionality and aesthetics, enhancing airflow efficiency for better thermal performance while widening the viewing angle for a more immersive experience
Manufacturer
ASUS
Part number
A31 PLUS TG ARGB WHITE
Condition
New
Category
System Components › Computer Cases
1GPA category
Hardware
Overview
Discover Hidden Potential
The ASUS A31 PLUS is a PC case crafted for minimalist mainstream DIY PC builders. It supports a variety of AIO coolers and graphics cards, and easily accommodates motherboards with hidden connector designs, ensuring a clean, clutter-free setup.
Specifications
Design
Material
Metal
Form factor
Midi Tower
Type
PC
Product colour
White
Supported motherboard form factors
ATX, micro ATX, Mini-ITX
Number of 3.5" bays
2
Number of 2.5" bays
2
Number of internal 3.5" bays
2
Number of expansion slots
7
Side window
Yes
Suitable for
Gaming
Illumination
Yes
Illumination colour
Multi
Tempered glass panel(s)
Yes
Anti-dust filter
Yes
Cable management
Yes
On/off button
Yes
Maximum CPU cooler height
16.5 cm
Maximum graphics card length
38 cm
Maximum PSU length
20 cm
Power supply
Power supply included
No
Power supply location
Bottom
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Combo headphone/mic port
Yes
USB 3.2 Gen 2x2 Type-C ports quantity
1
Cooling
Side fans installed
3x 120 mm
Rear fans installed
1x 120 mm
Number of rear fans supported (max)
1
Rear fans diameters supported
120,140 mm
Number of top fans supported (max)
3
Top fans diameters supported
120,140 mm
Liquid cooling capability
Yes
Front radiator installed
No
Rear radiator installed
No
Rear radiator sizes supported
120 mm
Top radiator installed
No
Top radiator sizes supported
140,240,360,120,280 mm
Storage
Supported HDD sizes
2.5,3.5"
Weight & dimensions
Width
238 mm
Depth
511 mm
Height
435 mm
Weight
9.1 kg
Packaging data
Package width
290 mm
Package depth
566 mm
Package height
493 mm
Package weight
10.1 kg
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
