ASUS

ASUS PE2200U-_ Intel Core Ultra 7 HDD+SSD

Part number 90AE01U1-M00050

RUGGED FANLESS COMPUTER PE2200U ASUS IOT PE2200U W/ CORE ULTRA 135U

  • Intel Core Ultra processor 100U series, with up to 64 GB DDR5
  • Rich I/O with 2 x LAN, 7 x USB and 4 x COM
  • Rich expansion capacity including PoE, CAN-bus and COM ports modules
  • Wide voltage range: 9 to 36V
  • Wide operating temperature range: -20°C to 60°C
Manufacturer
ASUS
Part number
90AE01U1-M00050
Condition
New
Category
Computer Systems › Desktop Computers
1GPA category
Hardware

Overview

ASUS IoT PE2200U is an intelligent edge computer featuring rich I/O capabilities, various connectivity options and fanless thermal design that is suitable for diverse IoT applications – and empowered by an Intel® Core™ Ultra processor 100U series. It features NPU support to delivers up to 11 TOPS, making it a powerful dedicated AI accelerator for diverse edge AI deployments.

PE2200U features up to four COM ports, seven USB ports, triple independent display ports and is primed for expansion – with options for PoE LAN, CAN-bus, COM ports module and more. This rugged edge computer is designed to accommodate both high performance and silent operation in challenging environments, achieving full CPU utilization while being cooled via an efficient, fanless thermal solution. It also benefits from a form-fitting design inherited from previous products in the series, minimizing upgrade stresses.

To offer enhanced features and to ensure optimal performance and flexibility of adapting to the surrounding environment, PE2200U meets the military-grade MIL-STD 810H standard and supports wide temperatures ranging from -20° to 60°C, wide-range 9 to 36V DC-in and versatile I/O interfaces for multiple vertical market applications. It also benefits from ASUS IoT’s world-class after-sales service and guaranteed long-term availability – ensuring that your investment is maximized.

Specifications

Processor
Processor manufacturerIntel
Processor familyIntel Core Ultra 7
Processor model165U
Processor cores12
Processor boost frequency4.9 GHz
Processor cache12 MB
Processor cache typeSmart Cache
Memory
Memory slots2x SO-DIMM
Memory clock speed5600 MHz
Supported memory typesDDR5-SDRAM
Storage
Storage mediaHDD+SSD
Number of storage drives supported2
HDD interfaceSATA III
SSD interfaceM.2
Graphics
On-board graphics cardYes
On-board graphics card modelIntel® Graphics
Discrete graphics cardNo
Network
Wi-FiNo
Ethernet LANYes
Ethernet LAN data rates10,100,1000,2500 Mbit/s
Ports & interfaces
USB 2.0 ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
HDMI ports quantity1
HDMI version2.0
DisplayPorts quantity1
Ethernet LAN (RJ-45) ports2
Line-outYes
Microphone inYes
RS‐232/422 portYes
Power
DC input voltage9 - 36 V
Operational conditions
Operating temperature (T-T)-20 - 60 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)10 - 95%
Certificates
CertificationEMC: CE, FCC, IC, BSMI; Safety: CE-LVD, UKCA, CB, BSMI, CCC
Weight & dimensions
Width254 mm
Depth147 mm
Height57 mm
Weight1.93 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
