Overview
The APC Smart-UPS RT is an online UPS with a power rating of 2000VA and output power capacity of 1800 watts. This model does not include battery and is rack-mountable. The UPS features double conversion online technology and sine wave output.
Specifications
Features
| UPS topology | Double-conversion (Online) |
|---|
| Output power capacity | 2 kVA |
|---|
| Output power | 1800 W |
|---|
| Waveform | Sine |
|---|
| Input operation voltage (min) | 85 V |
|---|
| Input operation voltage (max) | 155 V |
|---|
| Input frequency | 40 - 70 Hz |
|---|
| Output operation voltage (min) | 120 V |
|---|
| Output frequency | 50/60 Hz |
|---|
| Maximum current | 26 A |
|---|
| Surge energy rating | 432 J |
|---|
| Crest factor | 3:1 |
|---|
| Noise level | 55 dB |
|---|
Battery
| Battery voltage | 48 V |
|---|
Design
| Form factor | Rackmount |
|---|
| Product colour | Black |
|---|
| International Protection (IP) code | IP20 |
|---|
Operational conditions
| Operating temperature (T-T) | -40 - 74 °C |
|---|
| Storage temperature (T-T) | -40 - 85 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
Weight & dimensions
| Width | 432 mm |
|---|
| Depth | 260 mm |
|---|
| Height | 88 mm |
|---|
| Weight | 10 kg |
|---|
Packaging data
| Package width | 370 mm |
|---|
| Package depth | 535 mm |
|---|
| Package height | 186 mm |
|---|
| Package weight | 12 kg |
|---|
Logistics data
| Warranty period | 3 year(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
