Overview
"High density, double-conversion on-line power protection with scalable runtime."
Specifications
Features
| Rack capacity | 4U |
|---|
| Compatibility | APC Symmetra LX |
|---|
Power
| Input voltage | 230 / 400 3 phases |
|---|
| Output voltage | 230 V |
|---|
| DC input voltage | 230 V; 400 V 3 phases |
|---|
| Output power capacity | 4 kVA |
|---|
| Input current (max) | 18 A |
|---|
| Output connection type | hard wire 3-wire (H N + E) for 1 zone(s) |
|---|
Certificates
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
|---|
| Compliance certificates | RoHS, REACH, WEEE |
|---|
| Certification | C-Tick; CE; GOST; VDE |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
Weight & dimensions
| Width | 250 mm |
|---|
| Depth | 565 mm |
|---|
| Height | 150 mm |
|---|
| Weight | 15 kg |
|---|
Technical details
| Sustainable packaging | No |
|---|
| Packaging recycled materials | Recycled cardboard |
|---|
| SCIP number | a208548b-09a8-4680-97a6-ad17b46807b1 |
|---|
| Mounting | front |
|---|
| Preferred mounting position | no preference |
|---|
| Take-back system | No |
|---|
| Packaging without single use plastic | No |
|---|
Logistics data
| Customs product code (TARIC) | 8504909000 |
|---|
| Harmonized System (HS) code | 85079080 |
|---|
| Total carbon footprint (kg of CO2e) | 3133.3589010529254 |
|---|
