APC SYMMETRA PX uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
Part number SYPM10KF2
SYMMETRA PX 10KW POWER MODULE 208V HIGH EFFICIENCY
- Double-conversion (Online)
- 10 kVA 10000 W
- Waveform: Sine
- Rackmount Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SYPM10KF2
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Specifications
| UPS topology | Double-conversion (Online) |
|---|---|
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Waveform | Sine |
| Input operation voltage (min) | 117 V |
| Input operation voltage (max) | 239 V |
| Input frequency | 60 Hz |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 208 V |
| Output frequency regulation | 60 Hz |
| Efficiency | 94.7% |
| Emergency Power Off (EPO) | No |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Form factor | Rackmount |
|---|---|
| Product colour | Black |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | 15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 999.9 m |
| Non-operating altitude | 0 - 4500 m |
| Compliance certificates | RoHS |
|---|---|
| Certification | cUL Listed, FCC Part 15 Class A, ISO 14001, ISO 9001, UL 60950, UL Listed |
| Width | 483 mm |
|---|---|
| Depth | 700 mm |
| Height | 132 mm |
| Weight | 25.1 kg |
| Package width | 595 mm |
|---|---|
| Package depth | 795 mm |
| Package height | 225 mm |
| Package weight | 28.1 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
