Overview
Includes: CD with software, Rack Mounting brackets, Rack Mounting support rails, User Manual.
Specifications
Features
| Output power capacity | 2 kVA |
|---|
| Output power | 1400 W |
|---|
| Emergency Power Off (EPO) | Yes |
|---|
| Noise level | 60 dB |
|---|
| Audible alarm(s) | Yes |
|---|
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|
| Typical backup time at full load | 12.3 min |
|---|
| Typical backup time at half load | 28.4 min |
|---|
| Battery recharge time | 4 h |
|---|
Design
| Cable length | 1.83 m |
|---|
| Product colour | Black |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
| Non-operating altitude | 0 - 15000 m |
|---|
Certificates
| Certification | CSA,FCC 15 A,UL 1778 |
|---|
Weight & dimensions
| Weight | 117.7 kg |
|---|
Other features
| Interface | DB-9 RS-232,RJ-45 10 Base-T ethernet / SNMP/ Telnet,SmartSlot |
|---|
| Output connections | (12) NEMA 5-20R
(2) NEMA L6-20R |
|---|
| Input connection type | Hard Wire 3-wire (2PH + G) / NEMA L6-30P (30A Twist-Lock) |
|---|
| Dimensions (WxDxH) | 483 x 730 x 445 mm |
|---|
| Nominal input voltage | 208 V |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
