Overview
"This parts kit contains spare parts for the APC product model shown."
Specifications
Features
| Output power capacity | 2 kVA |
|---|
| Output power | 1400 W |
|---|
| Waveform | Sine |
|---|
| Number of input phases | 1 |
|---|
| Number of output phases | 1 |
|---|
| Single-phase input voltage supported | 240,230,220 V |
|---|
| Emergency Power Off (EPO) | Yes |
|---|
Ports & interfaces
| AC outlet types | NEMA L5-20R |
|---|
Battery
| Battery replacement accessibility | End-user |
|---|
| Typical backup time at full load | 12.6 min |
|---|
| Typical backup time at half load | 29.8 min |
|---|
| Battery recharge time | 4 h |
|---|
| Replacement battery cartridge | APC Replacement Battery SYBT2 |
|---|
Design
| Rack capacity | 8U |
|---|
| Product colour | Black |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
Technical details
| Sustainable packaging | No |
|---|
| Packaging recycled materials | Recycled cardboard |
|---|
| SCIP number | 8519b6fb-f7a9-44f8-be44-5dee68362126 |
|---|
| Preferred mounting position | lower |
|---|
| Take-back system | No |
|---|
| Packaging without single use plastic | No |
|---|
Certificates
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
|---|
| Compliance certificates | RoHS, REACH, WEEE |
|---|
| Certification | C-Tick; CE; IRAM; VDE |
|---|
Weight & dimensions
| Width | 483 mm |
|---|
| Depth | 730 mm |
|---|
| Height | 356 mm |
|---|
| Weight | 74.5 kg |
|---|
Packaging data
| Bundled software | - PowerChute Network Shutdown
- PowerChute plus for AIX v4.2.3
- PowerChute plus for HP-UX v 4.2.3
- PowerChute plus for Linux v 4.5.2
- PowerChute plus for Novell NetWare v4.3.3
- PowerChute plus for Red Hat Linux v 4.5.2.1
- PowerChute plus for Solaris v 4.5
- PowerChute Plus for Windows NT/2000 (English) v. 5.2.1 |
|---|
Logistics data
| Customs product code (TARIC) | 8504409590 |
|---|
| Harmonized System (HS) code | 85078000 |
|---|
| Country of origin | Philippines |
|---|
Other features
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
|---|
| Interface | DB-9 RS-232, RJ-45 10 Base-T ethernet for web/ SNMP/ Telnet management |
|---|
| Output connections | (8)IEC 320 C13
(2)IEC 320 C19 |
|---|
| Input connection type | Hard Wire 3-wire |
|---|
| Dimensions (WxDxH) | 482.6 x 730.3 x 355.6 mm |
|---|
| Nominal output voltage | 230 V |
|---|
| Output voltage note | Configurable for 220: 230 or 240 nominal output voltage |
|---|
| Nominal input voltage | 230 V |
|---|
| Output connection type | 8 IEC 60320C13; 2 IEC 60320C19 |
|---|
| Output voltage | 220 V |
|---|
| Mounting | front |
|---|
