APC Symmetra LX 12kVA Scalable to 16kVA N+1 Rack-mount, 208/240V
Part number SYA12K16RMP
PTO SYMMETRA LX 12KVA SCALABLE TO 16KVA N+1 RMT 208/240V
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SYA12K16RMP
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
Modular design
Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.
Configurable for N+1 internal redundancy
Provides high availabilty through redundancy by allowing configuration with one more Power Module than is necessary to support the connected load.
Redundant Intelligence Modules
Provides higher availability to the UPS connected loads by giving redundant communication paths to critical UPS functions.
Hot-swappable intelligence modules
Ensures clean, uninterrupted power to protected equipment during Intelligence Module replacement.
Hot-swappable power modules
Ensures clean, uninterrupted power to protected equipment during Power Module replacement.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Power Modules connected in parallel
Enhances availability by allowing immediate, seamless recovery from isolated module failures.
Battery modules connected in parallel
Delivers higher availability through redundant batteries.
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
Specifications
| Output power capacity | 12 kVA |
|---|---|
| Output power | 9800 W |
| Emergency Power Off (EPO) | Yes |
| Audible alarm(s) | Yes |
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Battery recharge time | 3 h |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Certification | CSA,FCC Part 15 Class A,UL 1778 |
|---|
| Weight | 242.7 kg |
|---|
| Battery type | SYBT5 |
|---|---|
| Interface | DB-9 RS-232, Smart-Slot |
| Output connections | 1x Hard Wire 4-wire (2PH + N +G) 4x NEMA L14-30R 8x NEMA L5-20R |
| Input connection type | Hard Wire 4-wire (2PH+N+G) |
| Dimensions (WxDxH) | 472 x 688 x 836 mm |
| Nominal input voltage | 208 V |
| Package dimensions (WxDxH) | 599 x 997 x 1054 mm |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
