APC Smart-UPS VT 15kVA uninterruptible power supply (UPS) 12000 W
Part number SUVTP15KF2B2S
PTO SMART-UPS VT 15KVA 208V W/2 BATT MOD STARTUP 8X5 INT MNT BYPASS
- 15 kVA 12000 W
- Sealed Lead Acid (VRLA)
- Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SUVTP15KF2B2S
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
Availability
Dual mains input
Increases availability by allowing the UPS to be connected to two separate power sources.
Scalable runtime
Allows additional run time to be quickly added as needed.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
Battery modules connected in parallel
Delivers higher availability through redundant batteries.
Serviceability
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Battery replacement without tools
Allows quick, easy battery replacement.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Shippable with modules installed
Enables pre-installation UPS staging and testing and faster installation.
Modular design
Provides fast serviceability and reduced maintenance requirements via self-diagnosing, field-replaceable modules.
Specifications
| Output power capacity | 15 kVA |
|---|---|
| Output power | 12000 W |
| Input frequency | 40/70 Hz |
| Emergency Power Off (EPO) | Yes |
| Audible alarm(s) | Yes |
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Battery recharge time | 5 h |
| Hot-swap battery | Yes |
| Product colour | Black |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -50 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 999.9 m |
| Non-operating altitude | 0 - 15000 m |
| Certification | cUL Recognized,ISO 14001,ISO 9001,UL 1778 |
|---|
| Weight | 396.8 kg |
|---|
| Package weight | 428.2 kg |
|---|
| Battery type | VRLA |
|---|---|
| Interface | DB-9 RS-232, Smart-Slot |
| Output connections | 1x Hard Wire 5-wire (3PH + N + G) 1x Screw Terminals |
| Input connection type | Hard Wire 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 356 x 813 x 1499 mm |
| Output voltage note | Configurable for 208 and 220V - 3 Phase |
| Nominal input voltage | 208 V |
| Package dimensions (WxDxH) | 650 x 1062 x 1643 mm |
