Overview
High density, double-conversion on-line power protection with scalable runtime.
- Low operating and maintenance costs with proven reliability and intelligent battery management.
- Avoids costly power problems by keeping your IT equipment and data protected and available.
- Peace of mind that comes with full equipment compatibility and reliability of a leader
- Save time with easy and convenient remote accessibility.
Specifications
Features
| UPS topology | Double-conversion (Online) |
|---|
| Output power capacity | 8 kVA |
|---|
| Output power | 8000 W |
|---|
| Waveform | Sine |
|---|
| Input operation voltage (min) | 100 V |
|---|
| Input operation voltage (max) | 275 V |
|---|
| Input frequency | 40 - 70 Hz |
|---|
| Output operation voltage (min) | 208 V |
|---|
| Output operation voltage (max) | 240 V |
|---|
| Output frequency | 50/60 Hz |
|---|
| Automatic Voltage Regulation (AVR) | Yes |
|---|
| Surge energy rating | 480 J |
|---|
| Efficiency | 98.5% |
|---|
| Crest factor | 3:1 |
|---|
| Emergency Power Off (EPO) | Yes |
|---|
| Output voltage Total Harmonic Distortion (THD) | 2% |
|---|
| Noise level | 55 dB |
|---|
| Surge protection | Yes |
|---|
| Power protection features | Overload |
|---|
| Audible alarm(s) | Yes |
|---|
| Auto-restart | Yes |
|---|
Ports & interfaces
| AC outlet types | C13 coupler, C19 coupler |
|---|
| AC outlets quantity | 11 AC outlet(s) |
|---|
| USB 2.0 ports quantity | 1 |
|---|
| Ethernet LAN (RJ-45) ports | 3 |
|---|
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|
| Battery capacity | 1716 Ah |
|---|
| Typical backup time at full load | 5 min |
|---|
| Typical backup time at half load | 14 min |
|---|
| Battery recharge time | 1.5 h |
|---|
| Hot-swap battery | Yes |
|---|
| Automatic battery test | Yes |
|---|
| Cold start | Yes |
|---|
Design
| Form factor | Tower |
|---|
| Housing material | Steel |
|---|
| Product colour | Black |
|---|
| Display type | LCD |
|---|
| LED indicators | Battery replacement |
|---|
| International Protection (IP) code | IP20 |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
Packaging content
| Cables included | USB cable |
|---|
| Quick installation guide | Yes |
|---|
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Width | 263 mm |
|---|
| Depth | 715 mm |
|---|
| Height | 432 mm |
|---|
| Weight | 111.6 kg |
|---|
Packaging data
| Resource CD | Yes |
|---|
| Package width | 600 mm |
|---|
| Package depth | 1000 mm |
|---|
| Package height | 461 mm |
|---|
| Package weight | 126.5 kg |
|---|
Logistics data
| Products per pallet | 1 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
