Overview
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 6kVA on-line 4U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (1P+N+E) input, 6x IEC 320 C13 and 4x IEC 320 C19 outlets, and 2x IEC jumper cables. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty.
Specifications
Features
| UPS topology | Double-conversion (Online) |
|---|
| Output power capacity | 6 kVA |
|---|
| Output power | 6000 W |
|---|
| Waveform | Sine |
|---|
| Input operation voltage (min) | 160 V |
|---|
| Input operation voltage (max) | 275 V |
|---|
| Input frequency | 40 - 70 Hz |
|---|
| Output operation voltage (min) | 220 V |
|---|
| Output operation voltage (max) | 240 V |
|---|
| Output frequency | 50/60 Hz |
|---|
| Surge energy rating | 480 J |
|---|
| Crest factor | 3:1 |
|---|
| Emergency Power Off (EPO) | Yes |
|---|
| Output voltage Total Harmonic Distortion (THD) | 3% |
|---|
| Noise level | 55 dB |
|---|
| Surge protection | Yes |
|---|
| Audible alarm(s) | Yes |
|---|
| Auto-restart | Yes |
|---|
| Temperature voltage compensation | Yes |
|---|
Ports & interfaces
| AC outlet types | C13 coupler, C19 coupler, IEC Jumpers |
|---|
| Power plug | Terminal |
|---|
| AC outlets quantity | 13 AC outlet(s) |
|---|
| USB port | Yes |
|---|
| USB 2.0 ports quantity | 1 |
|---|
| Serial interface | Yes |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Cabling technology | 10/100Base-T |
|---|
| SmartSlot | Yes |
|---|
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|
| Number of batteries supported | 1 |
|---|
| Battery life (max) | 5 year(s) |
|---|
| Battery recharge time | 1 h |
|---|
| Hot-swap battery | Yes |
|---|
| Automatic battery test | Yes |
|---|
Design
| Form factor | Rackmount |
|---|
| Rack capacity | 4U |
|---|
| Product colour | Black |
|---|
| Display type | LCD |
|---|
| LED indicators | Yes |
|---|
| International Protection (IP) code | IP20 |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
| Non-operating altitude | 0 - 15000 m |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
| Certification | CE, EAC, RCM, VDE, REACH |
|---|
Weight & dimensions
| Width | 432 mm |
|---|
| Depth | 719 mm |
|---|
| Height | 174 mm |
|---|
| Weight | 60 kg |
|---|
Packaging data
| Package width | 610 mm |
|---|
| Package depth | 960 mm |
|---|
| Package height | 370 mm |
|---|
| Package volume | 67000 cm³ |
|---|
Logistics data
| Products per pallet | 6 pc(s) |
|---|
| Harmonized System (HS) code | 85078000 |
|---|
| Total carbon footprint (kg of CO2e) | 55428.62 |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
