Overview
High density, double-conversion on-line power protection with scalable runtime
Includes : CD with software, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card.
Specifications
Features
| UPS topology | Double-conversion (Online) |
|---|
| Output power capacity | 2.2 kVA |
|---|
| Output power | 1800 W |
|---|
| Waveform | Sine |
|---|
| Input operation voltage (min) | 120 V |
|---|
| Input operation voltage (max) | 120 V |
|---|
| Input frequency | 40 - 70 Hz |
|---|
| Output operation voltage (min) | 120 V |
|---|
| Output operation voltage (max) | 120 V |
|---|
| Output frequency | 50/60 Hz |
|---|
| Surge energy rating | 340 J |
|---|
| Crest factor | 3:1 |
|---|
| Emergency Power Off (EPO) | Yes |
|---|
| Noise level | 55 dB |
|---|
| Surge protection | Yes |
|---|
| Power protection features | Overload |
|---|
| Audible alarm(s) | Yes |
|---|
| Web-based management | Yes |
|---|
| Audible alarm modes | Battery replacement |
|---|
| Auto-restart | Yes |
|---|
Ports & interfaces
| AC outlet types | NEMA 5–20R, NEMA L5-20R |
|---|
| Power plug | NEMA 5-20P |
|---|
| AC outlets quantity | 7 AC outlet(s) |
|---|
| USB port | Yes |
|---|
| Serial interface | Yes |
|---|
| Serial interface type | RJ-45 |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
|---|
| SmartSlot | Yes |
|---|
Battery
| Battery capacity | 306 VAh |
|---|
| Battery life (max) | 5 year(s) |
|---|
| Hot-swap battery | Yes |
|---|
| Automatic battery test | Yes |
|---|
| Cold start | Yes |
|---|
Design
| Form factor | Tower |
|---|
| Cable length | 1.83 m |
|---|
| Product colour | Black |
|---|
| Display type | LCD |
|---|
| LED indicators | Status, Battery replacement |
|---|
| International Protection (IP) code | IP20 |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -15 - 45 °C |
|---|
| Operating relative humidity (H-H) | 0 - 95% |
|---|
| Storage relative humidity (H-H) | 0 - 95% |
|---|
| Operating altitude | 0 - 3000 m |
|---|
| Non-operating altitude | 0 - 15000 m |
|---|
Certificates
| Compliance certificates | RoHS |
|---|
| Certification | CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, UL 1778 |
|---|
Packaging content
| Cables included | USB cable |
|---|
| Quick installation guide | Yes |
|---|
Sustainability
| Sustainability certificates | ENERGY STAR |
|---|
Weight & dimensions
| Width | 85 mm |
|---|
| Depth | 584 mm |
|---|
| Height | 432 mm |
|---|
| Weight | 25 kg |
|---|
Packaging data
| Bracket | Yes |
|---|
| Warranty card | Yes |
|---|
| Software CD | Yes |
|---|
| Package width | 599 mm |
|---|
| Package depth | 810 mm |
|---|
| Package height | 246 mm |
|---|
| Package weight | 30.8 kg |
|---|
| Package type | Box |
|---|
Logistics data
| Products per pallet | 12 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
