APC BY SCHNEIDER ELECTRIC

APC SRT2200RMXLAUS uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 1800 W

Part number SRT2200RMXLAUS

SMART UPS SRT 2200VA 120V TAA

  • Double-conversion (Online)
  • 2.2 kVA 1800 W
  • Waveform: Sine
  • Sealed Lead Acid (VRLA) 306 Ah
  • Rackmount Black
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SRT2200RMXLAUS
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware

Overview

Features

High density, double-conversion on-line power protection with scalable runtime

Includes: CD with software, Documentation CD, Installation guide, Rack Mounting brackets, Rack mounting hardware, Rack Mounting support rails, USB cable, Warranty card

Avoids costly power problems by keeping your IT equipment and data protected and available.

Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to battery during power events.

Low operating and maintenance costs with proven reliability and intelligent battery management.

Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.

Save time with easy and convenient remote/network accessibility.

Network manageable via serial, USB or Ethernet. Includes Powerchute® Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.

Peace of mind that comes with full equipment compatibility and reliability of a leader.

Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Specifications

Features
UPS topologyDouble-conversion (Online)
Output power capacity2.2 kVA
Output power1800 W
WaveformSine
Input frequency40/70 Hz
Output frequency50/60 Hz
Surge energy rating340 J
Crest factor3:1
Audible alarm(s)Yes
Ports & interfaces
AC outlet typesNEMA 5–20R, NEMA L5-20R
Power plugNEMA 5-20R
USB portYes
Serial interfaceYes
Serial interface typeRJ-45
SmartSlotYes
Battery
Battery technologySealed Lead Acid (VRLA)
Battery capacity306 Ah
Number of batteries supported1
Battery life (max)5 year(s)
Battery recharge time3 h
Replacement battery cartridgeAPCRBC141
Design
Form factorRackmount
Rack capacity2U
Cable length1.83 m
Product colourBlack
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m
Certificates
Compliance certificatesRoHS
CertificationCSA C22.2 No.107.3-05, FCC Part 15 Class A, OSHPD, TAA compliance, UL 1778
Packaging content
Rack mount kitYes
Cables includedUSB cable
ManualYes
Quick installation guideYes
Weight & dimensions
Width432 mm
Depth584 mm
Height85 mm
Weight24.9 kg
Packaging data
Package width599 mm
Package depth810 mm
Package height246 mm
Package weight34 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
