APC SRT10KRMTF uninterruptible power supply (UPS) 10 kVA 6 AC outlet(s)
Part number SRT10KRMTF
SMART-UPS SRT 10KVA 4U RM STEP DOWN TRANSFORMER CUST PAYS FREIGHT
- 10 kVA
- 6 AC outlet(s)
- Rackmount/Tower Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SRT10KRMTF
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
SRT10KRMTF Features
APC Smart-UPS SRT 10kVA 4U RM Step-Down Transformer
Includes : Mounting hardware , Rack Mounting brackets , Safety guide , User Manual , Warranty card
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Transformer for Step-down or Step-up or Isolation
Step down transformer placed upstream of the UPS to avoid inrush current and saturation eliminating need to oversize transformer
Smart-UPS Accessories Features & Benefits
Product Distribution
Antigua and Barbuda , Anguilla , Netherlands Antilles , Argentina , Aruba , Barbados , Bermuda , Bolivia , Brazil , Bahamas , Belize , Canada , Chile , Colombia , Costa Rica , Cuba , Dominica , Dominican Republic , Ecuador , Falkland Islands , Grenada , Guatemala , Guyana , Honduras , Haiti , Jamaica , Saint Kitts And Nevis , Cayman Islands , Saint Lucia , Mexico , Nicaragua , Panama , Peru , Puerto Rico , Paraguay , El Salvador , Trinidad and Tobago , United States , Uruguay , Saint Vincent And The Grenadines , Venezuela , U.S. Virgin Islands
Specifications
| Output power capacity | 10 kVA |
|---|---|
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 240 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 240 V |
| Maximum current | 60 A |
| AC outlet types | NEMA L14-30R, NEMA L5-20R |
|---|---|
| AC outlets quantity | 6 AC outlet(s) |
| Form factor | Rackmount/Tower |
|---|---|
| Product colour | Black |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Compliance certificates | RoHS |
|---|---|
| Certification | CE, CSA, UL Listed |
| Width | 432 mm |
|---|---|
| Depth | 749 mm |
| Height | 174 mm |
| Weight | 99.8 kg |
| Package width | 600 mm |
|---|---|
| Package depth | 1000 mm |
| Package height | 406 mm |
| Package weight | 124.7 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
