APC BY SCHNEIDER ELECTRIC
APC SMX750C uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 675 W 8 AC outlet(s)
Part number SMX750C
UPS X 750VA RACK TOWER LCD 120V
- Line-Interactive
- 0.75 kVA 675 W
- Waveform: Sawtooth
- 8 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Rackmount/Tower Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SMX750C
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
APC Smart-UPS X 750VA Rack/Tower LCD 120V with SmartConnect Port
- Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other ...
- Includes: Cat 5 Ethernet cable, Installation guide, Rack mounting brackets, Removable support feet, Smart UPS signalling RS-232 cable, USB cable, Warranty card
Specifications
| UPS topology | Line-Interactive |
|---|---|
| Output power capacity | 0.75 kVA |
| Output power | 675 W |
| Waveform | Sawtooth |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 120 V |
| Maximum current | 12 A |
| Surge energy rating | 645 J |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 40 dB |
| Audible alarm(s) | Yes |
| AC outlet types | NEMA 5–15R |
|---|---|
| AC outlets quantity | 8 AC outlet(s) |
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Battery recharge time | 3 h |
| Form factor | Rackmount/Tower |
|---|---|
| Rack capacity | 2U |
| Cable length | 2.4 m |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15240 m |
| Width | 89 mm |
|---|---|
| Depth | 490 mm |
| Height | 432 mm |
| Weight | 22.1 kg |
| Package width | 246 mm |
|---|---|
| Package depth | 620 mm |
| Package height | 589 mm |
| Package weight | 26.5 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
