APC BY SCHNEIDER ELECTRIC

APC Smart-UPS X 3000VA uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 7 AC outlet(s)

Part number SMX3000RMLV2U

SMART UPS X 3000VA RACK/TOWER LCD 100-127V

User-selectable low voltage setting of 100V-127V
Add up to 10 external battery packs (SMX120RMBP2U)
Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown
Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels

Manufacturer: APC BY SCHNEIDER ELECTRIC
Part number: SMX3000RMLV2U
Condition: New
Category: Power & Rack Equipment › Power Equipment
1GPA category: Hardware

Overview

Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2880VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

Specifications

Features
UPS topology	Line-Interactive
Output power capacity	3 kVA
Output power	2700 W
Waveform	Sine
Input operation voltage (min)	100 V
Input operation voltage (max)	127 V
Input frequency	50/60 Hz
Output operation voltage (min)	100 V
Output operation voltage (max)	127 V
Output frequency	50/60 Hz
Surge energy rating	540 J
Heat dissipation	276 BTU/h
Number of output phases	1
Efficiency	98%
Output voltage Total Harmonic Distortion (THD)	5%
Noise level	55 dB
Surge protection	Yes
Surge protection features	Network
Audible alarm(s)	Yes
Audible alarm modes	Alarm when on battery, Low battery alarm

Ports & interfaces
AC outlet types	NEMA 5–15R, NEMA 5–20R, NEMA L5-30R
AC outlets quantity	7 AC outlet(s)
USB port	Yes
Serial interface	Yes
Ethernet LAN (RJ-45) ports	1
SmartSlot	Yes

Battery
Battery technology	Lead-Acid
Typical backup time at full load	6.15 min
Battery recharge time	3 h

Design
Form factor	Rackmount/Tower
Rack capacity	2U
Cable length	2.4 m
Product colour	Black
Control type	Buttons
LED indicators	Yes

Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 15240 m

Certificates
Compliance certificates	RoHS
Certification	BSMI,CSA,EN 50091-2,EN 55022 A,FCC 15 A,NOM,TUV,UL 1778,VCCI A

Weight & dimensions
Width	432 mm
Depth	667 mm
Height	85 mm
Weight	38.5 kg

Packaging data
Package width	869 mm
Package depth	596 mm
Package height	243 mm
Package weight	45.4 kg

Logistics data
Export Control Classification Number (ECCN)	EAR99
Harmonized System (HS) code	8504.40

Other features
Battery type	RBC117

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
