Products › Power & Rack Equipment

APC BY SCHNEIDER ELECTRIC

APC SMX3000LVUS uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 10 AC outlet(s)

Part number SMX3000LVUS

TAA APC SMART-UPS X, LINE INTERACTIVE, 3KVA, RACK/TOWER 4U, 100V-127V, 6X 5-15

  • Line-Interactive
  • 3 kVA 2700 W
  • Waveform: Sine
  • 10 AC outlet(s)
  • Sealed Lead Acid (VRLA)
  • Rackmount Black
Manufacturer
APC BY SCHNEIDER ELECTRIC
Part number
SMX3000LVUS
Condition
New
Category
Power & Rack Equipment › Power Equipment
1GPA category
Hardware

Overview

Protect servers, switches, networking devices, and point-of-sale equipment with the APC Smart-UPS X 3000VA. APC Smart-UPS provide backup battery power during power outages and continuously safeguard devices from fluctuating power conditions and surges. With premium protection and simplified management, the 3000VA UPS ensures consistent and reliable connectivity at the most critical moments. With 10 outletsWith 2 switched outlet groups and a compatibilityWith external battery packs, this server UPS provides uninterrupted and scalable battery power to connected electronics Connect to 10 of the SMX120BP external battery packs to increase the amount of time the UPS can provide battery power to devices (battery packs sold separately) Use the intuitive LCD interface and PowerChute software to configure settings and monitor usage A SmartSlot in the back of the UPS offers the option to add a network management card to remotely manage the UPS over the network (network cards sold separately) The SMX3000LVUS converts from a tower or stand-alone UPS to a rack mount UPS, offering flexibility in various installations Package contains UPS, CD with software, Documentation CD, Installation guide, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, Removable support feet, Smart UPS signalling RS-232 cable & USB cable This 3000watt ups offers an grreen mode to ensure you are operating at the highest level of efficiency while it’s smart battery management maximizes performance Automatic Voltage Regulation (AVR) adjusts voltages ensuring reliable power while preserving battery life

Specifications

Features
UPS topologyLine-Interactive
Output power capacity3 kVA
Output power2700 W
WaveformSine
Input operation voltage (min)100 V
Input operation voltage (max)127 V
Input frequency50/60 Hz
Output operation voltage (min)100 V
Output operation voltage (max)127 V
Output frequency50/60 Hz
Surge energy rating540 J
Efficiency98%
Noise level55 dB
Audible alarm(s)Yes
Audible alarm modesAlarm when on battery, Low battery alarm
Ports & interfaces
AC outlet typesNEMA 5-15R, NEMA L5-20R, NEMA L5-30R
Power plugNEMA L5-30P
AC outlets quantity10 AC outlet(s)
USB portYes
USB port typeUSB Type-B
Battery
Battery technologySealed Lead Acid (VRLA)
Battery life (max)5 year(s)
Battery recharge time3 h
Design
Form factorRackmount
Rack capacity4U
Cable length2.44 m
Product colourBlack
Control typeButtons
Display typeLED
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Certificates
Compliance certificatesRoHS
Sustainability
Doesn't containMercury
Weight & dimensions
Width178 mm
Depth483 mm
Height432 mm
Weight38.6 kg
Packaging data
Package width633 mm
Package depth586 mm
Package height330 mm
Package weight47.7 kg

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
