Products › Power & Rack Equipment
APC Smart-UPS X uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 11 AC outlet(s)
Part number SMX3000HVT
SMX3000HVT - UPS - RACK/TOWER - LINE-INTERACTIVE - 208V - 2.7KW - 3000VA - RS-23
- Line-Interactive
- 3 kVA 2700 W
- Waveform: Sine
- 11 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Rackmount/Tower Black
- Manufacturer
- APC BY SCHNEIDER ELECTRIC
- Part number
- SMX3000HVT
- Condition
- New
- Category
- Power & Rack Equipment › Power Equipment
- 1GPA category
- Hardware
Overview
APC Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Includes : CD with software , Documentation CD , Rack Mounting Brackets , Smart UPS signalling RS-232 cable , USB cable , User Manual
Availability
- Disconnected battery notification
Warns when a battery is not available to provide backup power.
- Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
- Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
- Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Manageability
- USB connectivity
Provides management of the UPS via a USB port (not available on all models).
- Disconnected battery notification
Warns when a battery is not available to provide backup power.
- LED status indicators
Quickly understand unit and power status with visual indicators.
- Serial connectivity
Provides management of the UPS via a serial port.
- Audible alarms
Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
- Network manageable
Specifications
| UPS topology | Line-Interactive |
|---|---|
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Waveform | Sine |
| Input operation voltage (min) | 141 V |
| Input operation voltage (max) | 280 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Surge energy rating | 645 J |
| Crest factor | 3:1 |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 55 dB |
| Surge protection | Yes |
| Audible alarm(s) | Yes |
| Web-based management | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm |
| Auto-restart | Yes |
| AC outlet types | C13 coupler, C19 coupler, NEMA L6-20R, IEC Jumpers |
|---|---|
| Power plug | NEMA L6-20P |
| AC outlets quantity | 11 AC outlet(s) |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| SmartSlot | Yes |
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Battery capacity | 738 VAh |
| Battery life (max) | 5 year(s) |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Automatic battery test | Yes |
| Form factor | Rackmount/Tower |
|---|---|
| Rack capacity | 4U |
| Product colour | Black |
| Display type | LED |
| LED indicators | Status |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Compliance certificates | RoHS |
|---|---|
| Certification | C-tick, CE, CSA, EN 50091-1, EN 50091-2, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE, REACH |
| Rack mount kit | Yes |
|---|---|
| Cables included | RS-232, USB cable |
| Manual | Yes |
| Sustainability certificates | ENERGY STAR |
|---|
| Width | 178 mm |
|---|---|
| Depth | 483 mm |
| Height | 432 mm |
| Weight | 38.6 kg |
| Resource CD | Yes |
|---|---|
| Software CD | Yes |
| Package width | 586 mm |
| Package depth | 633 mm |
| Package height | 330 mm |
| Package weight | 47.7 kg |
| Products per pallet | 6 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
